Airtac ACQ Ultra Thin Air Cylinder ACQ12X20LB
$22.29
Regular price
$29.79
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ACQ12X20LB
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with JIS standards;
2. Features C-shaped retaining rings for securing cylinder body to front/rear covers, with riveted piston-rod assembly ensuring compactness and reliability;
3. Precision-honed bore surface enhances wear resistance and operational longevity;
4. Extended front cover guiding system improves alignment stability;
5. Space-saving profile maximizes installation flexibility in confined spaces;
6. Integrated sensor grooves along cylinder periphery facilitate seamless sensor mounting;
7. Comprehensive selection of standardized mounting accessories available;
Category: Compact Cylinders | Brand: AIRTAC | Series: ACQ
Installation guidelines:
Maintain 0.5mm minimum clearance between magnetic sensor and cylinder body.
Use anti-rotation mechanism for applications with torque loads. Lubricate monthly
with ISO VG32 hydraulic oil in continuous operation environments.
2. Features C-shaped retaining rings for securing cylinder body to front/rear covers, with riveted piston-rod assembly ensuring compactness and reliability;
3. Precision-honed bore surface enhances wear resistance and operational longevity;
4. Extended front cover guiding system improves alignment stability;
5. Space-saving profile maximizes installation flexibility in confined spaces;
6. Integrated sensor grooves along cylinder periphery facilitate seamless sensor mounting;
7. Comprehensive selection of standardized mounting accessories available;
Category: Compact Cylinders | Brand: AIRTAC | Series: ACQ
AirTAC ACQ12X20LB Ultra-Slim Cylinder Technical Specifications
- Model Code Breakdown: ACQ12X20LB
- ACQ: Ultra-slim cylinder series
- 12: 12mm bore diameter
- 20: 20mm stroke length
- L: Built-in magnet for position sensing
- B: Double-acting type
- Operating Principle: Pneumatic double-acting cylinder
- Bore Size: Ø12mm (precision honed tube)
- Stroke: 20mm ±0.5mm
- Working Pressure Range: 0.15-0.8 MPa (21.7-116 psi)
- Temperature Range: -20℃ to +80℃ (NBR seals)
- Port Size: M5x0.8 (ISO standard thread)
- Cushioning: Adjustable rubber buffers at both ends
- Piston Rod Material: Stainless steel SUS304
- Tubing Material: Anodized aluminum alloy
- Seal Material: Nitrile Butadiene Rubber (NBR)
- Mounting Options: Basic type (no pre-mounted brackets)
- Repeat Positioning Accuracy: ±0.1mm
- IP Rating: IP65 (dust-tight & protected against water jets)
- Weight: 0.12kg ±5%
- Dimensions:
- Length: 70mm (compact design: L = stroke×2 + 30mm)
- Width: 32mm (including sensor slot)
- Height: 20mm (ultra-low profile design)
This space-optimized pneumatic cylinder features a 2.5mm wall thickness precision tube and integrated magnetic field detection. The hardened piston rod (HRC 45-50) ensures wear resistance in high-cycle applications. Requires 5μm filtered compressed air with ISO 8573-1:2010 Class 3.4.3 air quality.
Industrial Applications:
- PCB handling in SMT machines
- Precision valve actuation in medical devices
- Compact grippers in SCARA robots
- Paper feed mechanisms in high-speed printers
- Positioning stages in optical inspection systems
Installation guidelines:
Maintain 0.5mm minimum clearance between magnetic sensor and cylinder body.
Use anti-rotation mechanism for applications with torque loads. Lubricate monthly
with ISO VG32 hydraulic oil in continuous operation environments.
Performance Characteristics:
- Max speed: 500mm/s (with proper cushioning adjustment)
- Service life: 5,000km travel distance (under standard conditions)
- Air consumption: 0.18L/min at 0.5MPa (single stroke)
| Property | Property Value |
|---|---|
| sku | ACQ12X20LB |
| Mounting Type | Axial Mounting Bracket |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <20mm> |
