Airtac ACQ Ultra Thin Air Cylinder ACQ12X25BLB
2. Features C-shaped retaining rings for securing cylinder body to front/rear covers, with riveted piston-rod assembly ensuring compactness and reliability;
3. Precision-honed bore surface enhances wear resistance and operational longevity;
4. Extended front cover guiding system improves alignment stability;
5. Space-saving profile maximizes installation flexibility in confined spaces;
6. Integrated sensor grooves along cylinder periphery facilitate seamless sensor mounting;
7. Comprehensive selection of standardized mounting accessories available;
Category: Compact Cylinders | Brand: AIRTAC | Series: ACQ
AirTAC ACQ Ultra-Thin Cylinder ACQ12X25BLB Technical Specifications
- Model: ACQ12X25BLB
- Series: ACQ (Ultra-Compact Design)
- Bore size: 12mm
- Stroke: 25mm
- Action type: Double-acting with magnetic piston
- Operating pressure: 0.05–0.9 MPa
- Buffer type: Adjustable rubber cushion
- Port size: M5x0.8 (Standard) / NPT1/8 (Optional)
- Piston rod thread: M4x0.7 (Female)
- Ambient temperature: -20℃ to 80℃
- Seal material: NBR/PU combination
- Body material: Anodized aluminum alloy
- Weight: 0.27kg (0.6 lbs)
- Dimensions:
- Total length (L): 83mm (3.27")
- Width (W): 22mm (0.87")
- Height (H): 22mm (0.87")
- Mounting hole spacing: 16mm (0.63")
- Max theoretical thrust: 11.6kgf @0.5MPa
- Air consumption: 5.8cm³/stroke @0.5MPa
- Magnetic sensor compatibility: D-A12 series
- ISO standard: 6432 (Compact cylinder specifications)
Ultra-slim profile cylinder featuring a 30% reduced cross-section compared to standard models, with integrated T-slot mounting grooves for flexible installation. The dual-seal piston design ensures ≤0.5mm/s leakage rate at maximum pressure. Special anti-rotation mechanism prevents piston spin during high-speed operation (up to 1.5m/s).
- PCB handling robots in electronics manufacturing
- Micro-precision clamping in optical lens assembly
- Medical device actuators requiring sterilization compatibility
- Space-constrained automation in semiconductor FOUP handlers
- Miniature sorting mechanisms for pharmaceutical blister packs
Installation protocol:
Apply 0.01-0.03Nm torque during mounting to prevent body deformation.
Use ISO VG32 lubricant for high-cycle applications (>1M cycles).
Magnetic sensors require 1.5mm axial clearance from cylinder surface.
| Property | Property Value |
|---|---|
| sku | ACQ12X25BLB |
| Mounting Type | Axial Mounting Bracket |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <25 mm> |
