Airtac ACQ Ultra Thin Air Cylinder ACQ12X30S
2. Features C-shaped retaining rings for securing cylinder body to front/rear covers, with riveted piston-rod assembly ensuring compactness and reliability;
3. Precision-honed bore surface enhances wear resistance and operational longevity;
4. Extended front cover guiding system improves alignment stability;
5. Space-saving profile maximizes installation flexibility in confined spaces;
6. Integrated sensor grooves along cylinder periphery facilitate seamless sensor mounting;
7. Comprehensive selection of standardized mounting accessories available;
Category: Compact Cylinders | Brand: AIRTAC | Series: ACQ
AirTAC ACQ12X30S Ultra-Compact Cylinder Specifications
- Model: ACQ12X30S
- Series: ACQ (Ultra-Thin Design)
- Bore size: 12mm
- Stroke: 30mm
- Mounting type: Basic non-ported
- Operating pressure: 0.15–0.8 MPa
- Cushion type: Adjustable rubber cushion (both ends)
- Port size: M5x0.8 (standard)
- Piston rod thread: M5x0.8 (male thread)
- Seal material: Polyurethane (PU) + Nitrile rubber (NBR)
- Ambient temperature: -20℃ to 80℃
- Weight: 0.25kg ±5%
- Dimensions (L×W×H):
- Body length: 58mm
- Total length (extended): 88mm
- Width: 30mm
- Height: 12.5mm (excluding mounting hardware)
- Rod end type: Female threaded pin eye
- Protection rating: IP54 (standard)
- Lubrication: Pre-lubricated (DOP-free)
The ACQ12X30S represents AirTAC's thinnest cylinder series (only 12.5mm height), engineered for space-constrained automation systems requiring precise linear motion. Features dual adjustable cushions for smooth stroke termination and anodized aluminum construction for corrosion resistance. Optimized for high-frequency operations (up to 5Hz) with minimal stick-slip effect.
- PCB handling in SMT assembly lines
- Precision clamping in semiconductor wafer processing
- Medical device actuation mechanisms
- Collaborative robot end-effector positioning
- Packaging machine gate control
Installation note:
For optimal performance, maintain alignment within ±2° angular deviation. Use AirTAC VG-68#
lubricant if re-lubrication is required. Maximum side load: 2.5N. Avoid mounting in vertical
downward orientation without external guides.
- Air filtration: 5-40μm particulate
- Recommended air dryness: Pressure dew point -10℃ below ambient
- Flow control: Install speed controllers within 300mm of ports
| Property | Property Value |
|---|---|
| sku | ACQ12X30S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | 30mm |
