Airtac ACQ Ultra Thin Air Cylinder ACQ20X20SB
2. Features C-shaped retaining rings for securing cylinder body to front/rear covers, with riveted piston-rod assembly ensuring compactness and reliability;
3. Precision-honed bore surface enhances wear resistance and operational longevity;
4. Extended front cover guiding system improves alignment stability;
5. Space-saving profile maximizes installation flexibility in confined spaces;
6. Integrated sensor grooves along cylinder periphery facilitate seamless sensor mounting;
7. Comprehensive selection of standardized mounting accessories available;
Category: Compact Cylinders | Brand: AIRTAC | Series: ACQ
AirTAC ACQ20X20SB Ultra-Thin Cylinder Specifications
- Model: ACQ20X20SB
- Type: Single-acting (spring return)
- Bore size: 20mm
- Stroke: 20mm
- Operating pressure: 0.15–0.8 MPa
- Port size: M5x0.8 (standard) / Optional: G1/8
- Piston speed: 50–800 mm/s
- Ambient temperature: -20℃ to 80℃
- Cushioning: Adjustable rubber buffer
- Mounting style: Basic foot mounting (MF1) / Optional: Front flange (FF)
- Seal material: NBR (Nitrile rubber)
- Weight: 0.25 kg ±5%
- Dimensions (L×W×H): 72mm × 20mm × 20mm (at full retraction)
- Rod thread: M5×0.8 (male thread)
- Protection rating: IP40
Ultra-compact cylinder optimized for space-constrained automation systems. Features a 60% reduced axial length compared to standard cylinders, with anodized aluminum construction for corrosion resistance. Requires filtered air (5-40μm) with ISO VG32 or equivalent lubrication. Includes built-in magnet for position sensing compatibility.
- PCB handling robots in electronics manufacturing
- Medical device clamping mechanisms
- Precision valve actuation in analytical instruments
- Packaging machine ejector systems
- Semiconductor wafer processing equipment
Installation note:
Maintain 0.5mm minimum clearance between piston rod and guide bushings.
For vertical mounting, reduce operating pressure by 20% to compensate for spring force.
Lubricate through air supply (oil mist type recommended).
| Property | Property Value |
|---|---|
| sku | ACQ20X20SB |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | <20mm> |
