Airtac ACQ Ultra Thin Air Cylinder ACQ20X30SB
2. Features C-shaped retaining rings for securing cylinder body to front/rear covers, with riveted piston-rod assembly ensuring compactness and reliability;
3. Precision-honed bore surface enhances wear resistance and operational longevity;
4. Extended front cover guiding system improves alignment stability;
5. Space-saving profile maximizes installation flexibility in confined spaces;
6. Integrated sensor grooves along cylinder periphery facilitate seamless sensor mounting;
7. Comprehensive selection of standardized mounting accessories available;
Category: Compact Cylinders | Brand: AIRTAC | Series: ACQ
AirTAC ACQ20X30SB Ultra-Thin Cylinder Specifications
- Model: ACQ20X30SB
- Type: Double-acting single rod compact cylinder
- Bore size: 20mm
- Stroke: 30mm (±1.5mm tolerance)
- Operating pressure: 0.15–0.8 MPa
- Port size: M5x0.8 (dual ports)
- Cushion type: Rubber buffer (both ends)
- Piston material: Aluminum alloy (hard anodized)
- Rod material: Stainless steel SUS304
- Seal material: NBR (nitrile rubber)
- Temperature range: -20℃ to 80℃
- Weight: 0.25kg (excluding accessories)
- Dimensions:
80mm (total length) × 34mm (width with mounting) × 20mm (height)
*Cylinder body: Ø20mm × 53mm (retracted length) - Mounting options: Foot-mounted (standard), front flange (optional)
- ISO standard: Compliant with ISO 6432:2015
Ultra-flat cylinder with 20% reduced profile height compared to standard models, featuring space-saving design for high-density automation layouts. Precision honed tube ensures ≤0.1mm concentricity for smooth operation. Integrated magnet slot (T-slot design) enables easy sensor mounting for position feedback. Pre-lubricated for maintenance-free operation under normal conditions.
- PCB handling robots in electronics assembly
- Medical device actuation mechanisms
- Packaging machine ejector systems
- Cleanroom-compatible automation (low particle emission)
- 3-axis gantry pick-and-place units
Installation guidelines:
Maximum side load ≤10N. For vertical mounting, use locknut (M12x1.25)
to secure rod end. Lubricate every 5 million cycles with ISO VG32 turbine oil
in high-usage scenarios. Avoid rapid pressure changes >0.5MPa/sec.
| Property | Property Value |
|---|---|
| sku | ACQ20X30SB |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 30mm |
