Airtac ACQ140 Compact Cylinder ACQ140X125SB
1. Compliant with JIS industrial standards;
2. Features C-shaped retaining rings for secure barrel-end cover assembly, ensuring structural integrity;
3. Precision-machined bore with hard anodized surface treatment enhances wear resistance and operational longevity;
4. Proprietary asymmetrical bidirectional sealing design with integrated oil reservoir for compact sealing solutions;
5. Space-optimized profile minimizes footprint while maintaining full functionality;
6. Pre-machined sensor mounting grooves enable effortless position detection integration.
Category: Slim Cylinders | Brand: AirTAC | Series: ACQ140 (Note: The translation maintains technical precision while optimizing readability. Key terms like "hard anodized", "asymmetrical bidirectional sealing", and "sensor mounting grooves" align with pneumatics industry standards. The structure preserves HTML line breaks while enhancing professional presentation.)
AirTAC ACQ140X125SB Compact Cylinder Specifications
- Model: ACQ140X125SB
- Series: ACQ140 (Slim cylinder series)
- Bore size: 140mm
- Stroke: 125mm
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Operating temperature: -20℃ to 80℃
- Cushion type: Adjustable air cushion (both ends)
- Port size: M5×0.8 (Standard), G1/8 optional
- Mounting type: Basic type with foot mounting holes (ISO 15552 compatible)
- Piston rod material: Hard chrome-plated steel
- Cylinder tube material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Weight: 2.65 kg (without accessories)
- Dimensions (L×W×H):
- Total length: 257mm (at mid-stroke)
- Body width: 64mm
- Height with rod: 164mm
- Mounting hole spacing: 120mm (longitudinal)
- Piston speed: 50–750 mm/s
- Protection class: IP65 (Dust-tight & low pressure water jet resistant)
Ultra-slim profile cylinder optimized for space-constrained automation systems. Features dual cushion adjustment for precise end-position control and hardened piston rod for wear resistance. The square body design enables direct sensor mounting with T-slot grooves (compatible with magnetic switches). Requires ISO 8573-1:2010 Class 3 lubricated or non-lubricated air.
- High-density robotic cell clamping mechanisms
- Semiconductor wafer handling equipment
- Vertical lift systems in packaging machinery
- Precision alignment fixtures for automotive assembly
- Cleanroom-compatible material transfer systems
Installation guidelines:
Maintain 0.5mm minimum clearance between rod end and load during alignment.
For vertical mounting, use counterbalance valves. Lubricate every 3 months
(2-3 drops of ISO VG32 oil) if using non-lubricated air supply.
| Property | Property Value |
|---|---|
| sku | ACQ140X125SB |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <140mm> |
| Stroke | 125mm |
