Airtac ACQ140 Compact Cylinder ACQ140X150S
1. Compliant with JIS industrial standards;
2. Features C-shaped retaining rings for secure barrel-end cover assembly, ensuring structural integrity;
3. Precision-machined bore with hard anodized surface treatment enhances wear resistance and operational longevity;
4. Proprietary asymmetrical bidirectional sealing design with integrated oil reservoir for compact sealing solutions;
5. Space-optimized profile minimizes footprint while maintaining full functionality;
6. Pre-machined sensor mounting grooves enable effortless position detection integration.
Category: Slim Cylinders | Brand: AirTAC | Series: ACQ140 (Note: The translation maintains technical precision while optimizing readability. Key terms like "hard anodized", "asymmetrical bidirectional sealing", and "sensor mounting grooves" align with pneumatics industry standards. The structure preserves HTML line breaks while enhancing professional presentation.)
AirTAC ACQ140X150S Thin Cylinder Specifications
- Model: ACQ140X150S
- Type: Single-acting spring return (compressed air operation)
- Bore size: Φ14mm (ISO 6432 standard)
- Stroke: 150mm (±0.5mm tolerance)
- Operating pressure: 0.05–0.9 MPa
- Ambient temperature: -20℃ to 80℃
- Port size: M5×0.8 (standard) / NPT1/8 (optional)
- Cushioning: Adjustable rubber buffer
- Piston speed: 50–800 mm/s
- Rod material: Stainless steel SUS304
- Tube material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Mounting type: Basic foot mounting (ISO 15552 accessory compatibility)
- Weight: 260g ±5g (without accessories)
- Dimensions:
- Length: 226mm (cylinder body + stroke)
- Width: 34mm (mounting base width)
- Height: 34mm (cylinder outer diameter)
Ultra-compact profile cylinder optimized for space-constrained automation systems. Features a corrosion-resistant construction with precision honed tube and low-friction seals. The dual-purpose guide slot allows both magnetic switch installation (for position feedback) and manual position adjustment. Requires ISO 8573-1 class 3 or cleaner compressed air.
- PCB handling robots in electronics manufacturing
- Precision clamping mechanisms in CNC tool changers
- Medical device actuation systems
- Packaging machine ejector mechanisms
- Automated optical inspection (AOI) equipment positioning
Installation guidelines:
Maintain ≤0.3mm alignment tolerance during mounting. For vertical installations,
use the anti-rotation guide slot with compatible brackets (AMQ series recommended).
Lubricate every 500,000 cycles using ISO VG32 turbine oil.
| Property | Property Value |
|---|---|
| sku | ACQ140X150S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <140mm> |
| Stroke | 150mm |
