Airtac ACQ140 Compact Cylinder ACQ140X175SB
1. Compliant with JIS industrial standards;
2. Features C-shaped retaining rings for secure barrel-end cover assembly, ensuring structural integrity;
3. Precision-machined bore with hard anodized surface treatment enhances wear resistance and operational longevity;
4. Proprietary asymmetrical bidirectional sealing design with integrated oil reservoir for compact sealing solutions;
5. Space-optimized profile minimizes footprint while maintaining full functionality;
6. Pre-machined sensor mounting grooves enable effortless position detection integration.
Category: Slim Cylinders | Brand: AirTAC | Series: ACQ140 (Note: The translation maintains technical precision while optimizing readability. Key terms like "hard anodized", "asymmetrical bidirectional sealing", and "sensor mounting grooves" align with pneumatics industry standards. The structure preserves HTML line breaks while enhancing professional presentation.)
AirTAC ACQ140X175SB Thin Cylinder Specifications
- Model: ACQ140X175SB
- Type: Compact ISO-compliant double-acting cylinder
- Bore size: 140mm
- Stroke: 175mm
- Operating pressure: 0.05–0.8 MPa
- Mounting style: Front flange/Foot mount (optional accessories)
- Cushioning: Adjustable rubber buffer
- Port size: G1/2 (ISO standard)
- Material:
- Tube: Hard anodized aluminum alloy
- End caps: Die-cast aluminum
- Piston rod: Chrome-plated stainless steel (SUS304)
- Seal material: Nitrile rubber (NBR) with wear-resistant ring
- Temperature range: -20℃ to 80℃
- Weight: 6.8kg (excluding accessories)
- Dimensions: 235mm(L) × 140mm(W) × 140mm(H)
- Rod thread: M20×1.5
- Protection rating: IP54 (standard)
- Piston speed: 50–800 mm/s (lubricated)
Ultra-flat profile cylinder optimized for space-constrained industrial automation. Features precision honed tube (Ra≤0.2μm) and dual anti-rotation guides for exceptional lateral load capacity (up to 30% of maximum thrust). Integrated magnet slots for sensor mounting enable position feedback. Optional corrosion-resistant version available for humid environments.
- Press machine ejection systems
- Robotic welding fixture clamping
- Lithium battery production line handling
- Automotive windshield installation mechanisms
- High-speed packaging machine actuators
Installation notes:
- Align cylinder axis within ±0.2° to prevent side load
- Use only compatible AirTAC Cushion Needle Valve (ASN06-01B) for speed control
- Apply ISO VG32 hydraulic oil for initial lubrication
- Allow 15mm minimum clearance around magnetic sensors
| Property | Property Value |
|---|---|
| sku | ACQ140X175SB |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <140mm> |
| Stroke | 175mm |
