Airtac ACQ140 Compact Cylinder ACQ140X200S
$326.84
Regular price
$334.34
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ACQ140X200S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
ACQ140 Series Slim Cylinder
1. Compliant with JIS industrial standards;
2. Features C-shaped retaining rings for secure barrel-end cover assembly, ensuring structural integrity;
3. Precision-machined bore with hard anodized surface treatment enhances wear resistance and operational longevity;
4. Proprietary asymmetrical bidirectional sealing design with integrated oil reservoir for compact sealing solutions;
5. Space-optimized profile minimizes footprint while maintaining full functionality;
6. Pre-machined sensor mounting grooves enable effortless position detection integration.
Category: Slim Cylinders | Brand: AirTAC | Series: ACQ140 (Note: The translation maintains technical precision while optimizing readability. Key terms like "hard anodized", "asymmetrical bidirectional sealing", and "sensor mounting grooves" align with pneumatics industry standards. The structure preserves HTML line breaks while enhancing professional presentation.)
Installation note:
Maintain ≤0.1mm/m alignment tolerance during mounting. Lubricate rod weekly with ISO VG32 hydraulic oil in high-cycling applications (＞500 strokes/hour). Avoid side-load exceeding 50N.
1. Compliant with JIS industrial standards;
2. Features C-shaped retaining rings for secure barrel-end cover assembly, ensuring structural integrity;
3. Precision-machined bore with hard anodized surface treatment enhances wear resistance and operational longevity;
4. Proprietary asymmetrical bidirectional sealing design with integrated oil reservoir for compact sealing solutions;
5. Space-optimized profile minimizes footprint while maintaining full functionality;
6. Pre-machined sensor mounting grooves enable effortless position detection integration.
Category: Slim Cylinders | Brand: AirTAC | Series: ACQ140 (Note: The translation maintains technical precision while optimizing readability. Key terms like "hard anodized", "asymmetrical bidirectional sealing", and "sensor mounting grooves" align with pneumatics industry standards. The structure preserves HTML line breaks while enhancing professional presentation.)
AirTAC ACQ140X200S Compact Cylinder Specifications
- Full model: ACQ140X200S (ACQ140 series)
- Bore size: 140mm
- Stroke: 200mm
- Mounting type: Foot/Flange/Trunnion options
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable pneumatic cushion
- Seal material: Nitrile rubber (NBR) standard
- Temperature range: -20℃ to 80℃
- Port size: PT1/4 (G1/8 optional)
- Piston speed: 50–800 mm/s
- Weight: 5.2kg (bare cylinder)
- Dimensions:
- Body length: 208mm
- Extended length: 408mm (stroke included)
- Width: 166mm (mounting base)
- Height: 160mm (including cushion screws)
- Rod thread: M16×1.5
- Protection rating: IP54 (standard)
- Optional accessories: Magnetic piston kit (for position sensing)
Ultra-low profile cylinder with optimized footprint-to-force ratio, featuring anodized aluminum construction for corrosion resistance. The double-acting design incorporates wear-resistant guide bushings and a chromium-plated piston rod. Designed for high cycle rates with ≤0.5mm lateral play at full extension.
Typical Applications:
- High-density automation cells in electronics assembly
- Press brake tooling positioning systems
- Vertical lift mechanisms in packaging lines
- Clamping fixtures for CNC machining centers
- Palletizing robot end-effector actuators
Installation note:
Maintain ≤0.1mm/m alignment tolerance during mounting. Lubricate rod weekly with ISO VG32 hydraulic oil in high-cycling applications (＞500 strokes/hour). Avoid side-load exceeding 50N.
| Property | Property Value |
|---|---|
| sku | ACQ140X200S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <140mm> |
| Stroke | <200mm> |
