Airtac ACQ140 Compact Cylinder ACQ140X250S
1. Compliant with JIS industrial standards;
2. Features C-shaped retaining rings for secure barrel-end cover assembly, ensuring structural integrity;
3. Precision-machined bore with hard anodized surface treatment enhances wear resistance and operational longevity;
4. Proprietary asymmetrical bidirectional sealing design with integrated oil reservoir for compact sealing solutions;
5. Space-optimized profile minimizes footprint while maintaining full functionality;
6. Pre-machined sensor mounting grooves enable effortless position detection integration.
Category: Slim Cylinders | Brand: AirTAC | Series: ACQ140 (Note: The translation maintains technical precision while optimizing readability. Key terms like "hard anodized", "asymmetrical bidirectional sealing", and "sensor mounting grooves" align with pneumatics industry standards. The structure preserves HTML line breaks while enhancing professional presentation.)
AirTAC ACQ140X250S Thin Cylinder Specifications
- Model: ACQ140X250S
- Type: Double-acting compact cylinder
- Bore size: 140mm
- Stroke: 250mm
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Port size: G1/2 (ISO standard)
- Mounting style: Basic type (optional front/rear flange, foot mounting)
- Piston rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR (nitrile rubber)
- Temperature range: -20℃ to 80℃
- Weight: 5.2kg (without accessories)
- Dimensions: 350mm(L) × 152mm(W) × 152mm(H) (including mounting brackets)
- Rod thread: M16×1.5
- Max theoretical thrust: 13,854N @0.7MPa
- Protection rating: IP65 (dust-tight & water jet resistant)
Ultra-flat profile cylinder optimized for space-constrained industrial automation systems. Features a reinforced anti-rotation guide mechanism and dual cushioning adjustment screws for precise stroke control. The hardened piston rod and wear-resistant seals enable 3,000km+ service life under standard conditions (0.5MPa, 50% duty cycle). Requires 40μm filtered lubricated air (ISO 8573-1 class 4).
- Press machine ejection systems (automotive stamping)
- Vertical lift mechanisms in warehouse robots
- Clamping devices for CNC machining centers
- Packaging line product positioning gates
- Solar panel tilt adjustment mechanisms
Installation tips:
- Allow 20mm clearance around cylinder body for heat dissipation
- Use dynamic load calculations when mounting vertically (max 30° deviation)
- Apply thread locker on mounting bolts (recommended torque: 45N·m)
- Pre-lubricate ports before initial operation (ISO VG32 equivalent)
| Property | Property Value |
|---|---|
| sku | ACQ140X250S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <140mm> |
| Stroke | <250MM> → <250mm> |
