Airtac ACQ140 Compact Cylinder ACQ140X30SB
1. Compliant with JIS industrial standards;
2. Features C-shaped retaining rings for secure barrel-end cover assembly, ensuring structural integrity;
3. Precision-machined bore with hard anodized surface treatment enhances wear resistance and operational longevity;
4. Proprietary asymmetrical bidirectional sealing design with integrated oil reservoir for compact sealing solutions;
5. Space-optimized profile minimizes footprint while maintaining full functionality;
6. Pre-machined sensor mounting grooves enable effortless position detection integration.
Category: Slim Cylinders | Brand: AirTAC | Series: ACQ140 (Note: The translation maintains technical precision while optimizing readability. Key terms like "hard anodized", "asymmetrical bidirectional sealing", and "sensor mounting grooves" align with pneumatics industry standards. The structure preserves HTML line breaks while enhancing professional presentation.)
AirTAC ACQ140X30SB Compact Cylinder Specifications
- Model: ACQ140X30SB
- Type: Single-acting spring return (optional double-acting)
- Bore size: 140mm
- Stroke: 30mm ±1mm
- Operating pressure: 0.05–0.8 MPa
- Cushion type: Adjustable pneumatic cushion
- Mounting style: Basic type (SB code: Square body with female threads)
- Port size: G1/2 (ISO 228 standard)
- Temperature range: -20℃ to 80℃
- Material:
- Cylinder tube: Aluminum alloy with hard anodization
- Piston rod: Stainless steel (SUS304)
- Seal material: NBR (Nitrile rubber)
- Weight: 2.35kg ±3% (without accessories)
- Dimensions:
- Length: 128mm (minimum retracted length)
- Width: 145mm (square body edge-to-edge)
- Height: 145mm (square body edge-to-edge)
Ultra-flat profile cylinder optimized for space-constrained industrial automation. Features wear-resistant chromium-plated piston rod and precision honed tube for smooth operation. The SB variant's square body design enables direct mounting with integrated threaded holes (M6×1.0 depth 12mm on four sides). Requires 40μm filtered lubricated air (ISO 8573-1 class 4).
- Clamping fixtures in CNC machining centers
- Vertical lifting mechanisms in semiconductor handlers
- Part ejection systems in injection molding machines
- Positioning gates in automated assembly lines
- Actuation in cleanroom robotics (optional stainless steel version)
Installation guidelines:
Maintain 0.5mm minimum clearance between rod end and load during alignment.
For vertical mounting, use double-acting configuration with external brake valve.
Lubricate through air supply (ISO VG32 equivalent oil mist).
| Property | Property Value |
|---|---|
| sku | ACQ140X30SB |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <140mm> |
| Stroke | 30mm |
