Airtac ACQJ12~25 Adjustable Compact Cylinder ACQJ12X20-20
2. Features C-shaped retaining ring assembly for cylinder body and end caps, paired with a swaged piston-rod connection for compact reliability;
3. Precision honed inner bore ensures exceptional wear resistance and extended service life;
4. Optimized front end cap with elongated guide track enhances alignment stability;
5. Space-efficient profile minimizes installation footprint;
6. Integrated sensor grooves along cylinder periphery enable seamless magnetic switch integration;
7. Versatile mounting brackets and accessories available for multiple configurations;
Category: Slim Cylinder Series | Brand: AIRTAC | Model Range: ACQJ12~25
AirTAC ACQJ12X20-20 Adjustable Compact Cylinder Specifications
- Series: ACQJ12~25 (Thin Type)
- Full model: ACQJ12X20-20
- Bore size: 12mm (0.47")
- Stroke: 20mm (0.79")
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Cushion type: Adjustable air cushion (both ends)
- Mounting style: Basic type (Standard MF1/MF2 optional)
- Weight: 0.22 kg (0.48 lbs)
- Dimensions:
- Total length: 76mm (3.0")
- Body width: 24mm (0.94")
- Height with rod: 41mm (1.61")
- Rod thread: M5×0.8
- Material:
- Cylinder tube: Aluminum alloy (hard anodized)
- Piston rod: SUS304 stainless steel
- Seals: NBR (Nitrile rubber)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Port size: M5×0.8 (1/8" NPT adaptor available)
- Lubrication: Pre-lubricated (Use ISO VG32 turbine oil)
Ultra-slim cylinder with 24mm profile width featuring dual adjustable pneumatic cushions for precise end-position control. The anodized barrel provides corrosion resistance, while the magnetic piston enables position sensing compatibility. Requires 40μm filtered air with ≤0.1mg/m³ oil content.
- PCB handling robots in electronics manufacturing
- Micro-pneumatic clamping in watch assembly
- Lab automation sample positioning stages
- Medical device actuation mechanisms
- Space-constrained packaging machinery
Installation tips:
Maximum side load ≤1.5N. For vertical mounting,
use rod-down orientation to prevent condensation accumulation.
Allow 2mm axial clearance during bracket installation.
| Property | Property Value |
|---|---|
| sku | ACQJ12X20-20 |
| Adjustable Stroke | <20mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <20mm> |
