Airtac ACQJ12~25 Adjustable Compact Cylinder ACQJ12X25-10
2. Features C-shaped retaining ring assembly for cylinder body and end caps, paired with a swaged piston-rod connection for compact reliability;
3. Precision honed inner bore ensures exceptional wear resistance and extended service life;
4. Optimized front end cap with elongated guide track enhances alignment stability;
5. Space-efficient profile minimizes installation footprint;
6. Integrated sensor grooves along cylinder periphery enable seamless magnetic switch integration;
7. Versatile mounting brackets and accessories available for multiple configurations;
Category: Slim Cylinder Series | Brand: AIRTAC | Model Range: ACQJ12~25
AirTAC ACQJ12X25-10 Adjustable Compact Cylinder Specifications
- Model: ACQJ12X25-10 (ACQJ series 12-25mm bore)
- Bore size: 12mm (ACQJ12)
- Stroke: 25mm (adjustable stroke mechanism)
- Operating pressure: 0.05–0.9 MPa
- Cushion type: Adjustable rubber cushion (both ends)
- Mounting style: Standard (optional foot/multi-mount brackets)
- Port size: M5x0.8 (dual ports)
- Piston speed: 50–700 mm/s
- Ambient temperature: -10℃ to 60℃
- Seal material: Polyurethane (NBR optional)
- Weight: 0.23 kg (bare cylinder)
- Dimensions:
- Length: 100mm (minimum retracted length)
- Width: 30mm (body width)
- Height: 24mm (profile height)
- Rod thread: M5x0.8 female
- ISO standard: 6432 compliant
Ultra-slim pneumatic cylinder featuring space-saving design with 24mm profile height, optimized for precision linear motion in confined spaces. The dual adjustable cushions allow smooth stroke-end deceleration control. Anodized aluminum construction with corrosion-resistant rod provides durability in industrial environments. Includes auto switch groove for sensor mounting.
- PCB handling robots in electronics assembly
- Medical device positioning mechanisms
- Automated packaging machine clamps
- Semiconductor wafer transfer systems
- 3C product testing equipment
Installation tips:
Lubricate with ISO VG32 hydraulic oil before initial use. Avoid side load exceeding 0.3N·m.
For adjustable stroke operation, limit rotation torque to 0.15N·m when turning stroke adjuster.
| Property | Property Value |
|---|---|
| sku | ACQJ12X25-10 |
| Adjustable Stroke | <10mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <25 mm> |
