Airtac ACQJ12~25 Adjustable Compact Cylinder ACQJ12X25-10B
2. Features C-shaped retaining ring assembly for cylinder body and end caps, paired with a swaged piston-rod connection for compact reliability;
3. Precision honed inner bore ensures exceptional wear resistance and extended service life;
4. Optimized front end cap with elongated guide track enhances alignment stability;
5. Space-efficient profile minimizes installation footprint;
6. Integrated sensor grooves along cylinder periphery enable seamless magnetic switch integration;
7. Versatile mounting brackets and accessories available for multiple configurations;
Category: Slim Cylinder Series | Brand: AIRTAC | Model Range: ACQJ12~25
AirTAC ACQJ12X25-10B Adjustable Compact Cylinder Specifications
- Series: ACQJ12~25 (Adjustable Stroke Series)
- Full model: ACQJ12X25-10B
- Bore size: 12mm (0.47")
- Stroke: 25mm (0.98") adjustable
- Stroke adjustment: ±2mm via external screw
- Mounting type: Basic type with single mounting hole
- Operating pressure: 0.1–0.9 MPa (14.5–130.5 PSI)
- Cushioning: Adjustable cushioning at both ends
- Port size: M5x0.8 (G1/8 optional)
- Seal material: NBR (Nitrile) with wear-resistant ring
- Temperature range: -20℃ to 80℃ (-4℉ to 176℉)
- Protection class: IP40 (Dust protected)
- Weight: 0.15kg (0.33lbs)
- Dimensions: 80mm(L) × 30mm(W) × 30mm(H)
- Rod end: Female thread M5x0.8
- Piston speed: 50–800 mm/s (with cushioning)
- Theoretical output: 11.3N at 0.5MPa (72.5°F)
Ultra-slim profile cylinder (height reduced 25% vs standard models) with stroke micro-adjustment capability. Features anodized aluminum construction with chrome-plated piston rod. Integrated magnet for position sensing compatibility. Includes shock-absorbing pads and anti-rotation guide for precision linear motion.
- Precision positioning in SMT equipment
- Medical device actuation mechanisms
- Robotic gripper adjustments
- Semiconductor wafer handling
- Packaging machine stopper controls
Installation note:
Maintain alignment within 0.2mm angular misalignment tolerance. Use only AirTAC Super Lubricant (ASL-120)
for maintenance. Stroke adjustment requires 2mm hex wrench (included). Allow 10% overstroke for calibration.
| Property | Property Value |
|---|---|
| sku | ACQJ12X25-10B |
| Adjustable Stroke | <10mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <25 mm> |
