Airtac ACQJ12~25 Adjustable Compact Cylinder ACQJ12X25-20
2. Features C-shaped retaining ring assembly for cylinder body and end caps, paired with a swaged piston-rod connection for compact reliability;
3. Precision honed inner bore ensures exceptional wear resistance and extended service life;
4. Optimized front end cap with elongated guide track enhances alignment stability;
5. Space-efficient profile minimizes installation footprint;
6. Integrated sensor grooves along cylinder periphery enable seamless magnetic switch integration;
7. Versatile mounting brackets and accessories available for multiple configurations;
Category: Slim Cylinder Series | Brand: AIRTAC | Model Range: ACQJ12~25
AirTAC ACQJ12X25-20 Adjustable Compact Cylinder Specifications
- Series: ACQJ12~25 Slim Cylinder Family
- Full model: ACQJ12X25-20
- Bore size: 12mm (0.47")
- Stroke: 25mm (0.98")
- Mounting type: M9 basic mount
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Cushioning: Adjustable pneumatic cushion
- Piston speed: 50–800 mm/s
- Ambient temperature: -20℃ to 80℃
- Port size: Rc1/8 (NPT1/8 optional)
- Seal material: NBR (Nitrile rubber)
- Weight: 0.25 kg (0.55 lbs)
- Dimensions (H×W×L): 50×34×75mm (1.97"×1.34"×2.95")
- Rod end: Female thread M5×0.8
- Max lateral load: 4.9N
- ISO standard: 6432 compliant
Ultra-slim profile cylinder with 7.5mm reduced body height compared to standard models, featuring dual adjustable cushion screws for precise stroke-end speed control. Anodized aluminum construction with chrome-plated piston rod resists corrosion in humid environments. Integrated mounting grooves enable tool-free accessory attachment.
- PCB handling robots in electronics assembly
- Dispenser nozzle positioning in pharmaceutical packaging
- Compact jig clamps for CNC machine tooling
- Ventilation damper actuators in medical devices
- Precision paper feed mechanisms in printing equipment
Maintenance tip:
Lubricate every 500,000 cycles using ISO VG32 turbine oil.
Avoid lateral force exceeding 0.5N·m during installation.
For vertical mounting, use model suffix "-20V" variant.
Critical note:
Requires 40μm filtered air with dew point -15℃ below ambient.
Do not disassemble cushion screws during operation.
Allow 2mm clearance around cylinder body for heat dissipation.
| Property | Property Value |
|---|---|
| sku | ACQJ12X25-20 |
| Adjustable Stroke | <20mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <25 mm> |
