Airtac ACQJ12~25 Adjustable Compact Cylinder ACQJ12X30-10
2. Features C-shaped retaining ring assembly for cylinder body and end caps, paired with a swaged piston-rod connection for compact reliability;
3. Precision honed inner bore ensures exceptional wear resistance and extended service life;
4. Optimized front end cap with elongated guide track enhances alignment stability;
5. Space-efficient profile minimizes installation footprint;
6. Integrated sensor grooves along cylinder periphery enable seamless magnetic switch integration;
7. Versatile mounting brackets and accessories available for multiple configurations;
Category: Slim Cylinder Series | Brand: AIRTAC | Model Range: ACQJ12~25
AirTAC ACQJ12X30-10 Adjustable Compact Cylinder Specifications
- Series: ACQJ12~25 (12mm-25mm bore options)
- Model: ACQJ12X30-10
- Bore size: 12mm
- Stroke: 30mm (adjustable via built-in stroke adjustment mechanism)
- Operating pressure: 0.05~0.9 MPa
- Medium: Clean dry air (ISO8573-1:2010 Class 3.4.2)
- Ambient temperature: -20℃ to 80℃
- Piston speed: 50~700 mm/s
- Cushioning: Adjustable rubber cushion at both ends
- Mounting type: Basic type (accessory brackets available)
- Port size: M5x0.8 (standard) with NPT1/8 optional
- Material: Aluminum alloy body, NBR seals
- Weight: 0.25kg ±5%
- Dimensions: 80mm(L) × 34mm(W) × 34mm(H)
- Repeat positioning accuracy: ±0.2mm
- Protection rating: IP54 (standard), IP67 optional
Ultra-slim profile cylinder (34mm cross-section) with 360° adjustable magnetic ring position, designed for precision short-stroke applications. Features double piston seals for enhanced leakage protection and wear-resistant guide bushings. Includes auto-lubrication design for maintenance-free operation under normal conditions.
- PCB handling robots in electronics manufacturing
- Precision clamping mechanisms in optical lens production
- Cartesian coordinate pick-and-place systems
- Medical device assembly automation
- Semiconductor wafer processing equipment
Installation note:
For optimal performance, maintain 0.5mm minimum clearance between magnetic sensor and cylinder body.
Use locknuts (not included) for stroke adjustment fixation. Lubricate through air supply (ISO VG32 equivalent)
if operating in high-cycle (>5Hz) applications.
| Property | Property Value |
|---|---|
| sku | ACQJ12X30-10 |
| Adjustable Stroke | <10mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | 30mm |
