Airtac ACQJ12~25 Adjustable Compact Cylinder ACQJ12X30-10B
2. Features C-shaped retaining ring assembly for cylinder body and end caps, paired with a swaged piston-rod connection for compact reliability;
3. Precision honed inner bore ensures exceptional wear resistance and extended service life;
4. Optimized front end cap with elongated guide track enhances alignment stability;
5. Space-efficient profile minimizes installation footprint;
6. Integrated sensor grooves along cylinder periphery enable seamless magnetic switch integration;
7. Versatile mounting brackets and accessories available for multiple configurations;
Category: Slim Cylinder Series | Brand: AIRTAC | Model Range: ACQJ12~25
AirTAC ACQJ12~25 Series Adjustable Slim Cylinder ACQJ12X30-10B Specifications
- Model Code: ACQJ12X30-10B
- Bore Size: 12mm (ACQJ12) | Available range: 12/16/20/25mm
- Stroke: 30mm (adjustable ±3mm via cushion mechanism)
- Operating Pressure: 0.05-0.9 MPa
- Mounting Type: MF1 (Front flange with 4 mounting holes)
- Cushioning: Adjustable air cushion (dual-side)
- Piston Speed: 50-800 mm/s
- Ambient Temperature: -10℃ to 70℃
- Port Size: M5x0.8 (standard) | Optional NPT1/8
- Body Material: Aluminum alloy (anodized)
- Seal Material: NBR (nitrile rubber)
- Weight: 0.25kg (without accessories)
- Dimensions: 90mm(L) × 60mm(W) × 85mm(H)
- Protection Class: IP40 (dust protected)
- Rod End: Female thread M5x0.8 (ISO 10242 standard)
Ultra-compact profile cylinder (only 26mm height) with precision stroke adjustment, designed for space-constrained automation systems. Features twin guide rods for enhanced lateral load capacity (max 5N·m moment resistance). Optional magnetic piston version (add "-M" suffix) for position sensing.
- PCB handling robots in electronics assembly
- Precision clamping mechanisms in CNC tool changers
- Miniature part ejection systems in injection molding
- Laboratory automation equipment requiring millimeter-level positioning
- Medical device actuators with sterilization compatibility
Installation Tips:
Maintain 0.5mm minimum clearance between cylinder and adjacent surfaces.
Use flexible couplings when connecting to guided mechanisms. Lubricate with ISO VG32 turbine oil
(1 drop per 1 million cycles). For vertical mounting, install exhaust mist lubricator.
| Property | Property Value |
|---|---|
| sku | ACQJ12X30-10B |
| Adjustable Stroke | <10mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | 30mm |
