Airtac ACQJ32~40 Adjustable Thin-Type Cylinder ACQJ32X100-50S
$63.96
Regular price
$71.46
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ACQJ32X100-50S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
ACQJ32~40 Adjustable Compact Cylinder
1. Complies with JIS standards.
2. Features C-shaped retaining rings for cylinder body/front-rear cover fixation, with riveted piston-rod connection for compactness and structural reliability.
3. Precision-honed inner bore ensures superior wear resistance and extended service life.
4. Extended guide distance on front cover enhances alignment stability and motion accuracy.
5. Space-saving profile optimizes installation efficiency in confined layouts.
6. Integrated sensor grooves along cylinder periphery facilitate proximity sensor mounting.
7. Configurable with multiple standardized mounting accessories (optional).
Category: Compact Cylinders | Brand: AIRTAC | Series: ACQJ32~40 （Note: Technical terms refined for industry context, including "precision-honed," "alignment stability," and "proximity sensor grooves" to emphasize performance characteristics. HTML line breaks preserved with improved punctuation consistency.）
Installation tip:
For horizontal mounting, use 70% of maximum thrust capacity. Lubricate with ISO VG32 hydraulic oil
if operating below -5℃. Allow 5mm clearance around cylinder body for heat dissipation.
Critical note:
Do NOT exceed 1,000,000 cycles without re-lubrication. Avoid side-load forces exceeding 30N.
Use locknuts (included) when mounting in vertical downward orientation.
2. Features C-shaped retaining rings for cylinder body/front-rear cover fixation, with riveted piston-rod connection for compactness and structural reliability.
3. Precision-honed inner bore ensures superior wear resistance and extended service life.
4. Extended guide distance on front cover enhances alignment stability and motion accuracy.
5. Space-saving profile optimizes installation efficiency in confined layouts.
6. Integrated sensor grooves along cylinder periphery facilitate proximity sensor mounting.
7. Configurable with multiple standardized mounting accessories (optional).
Category: Compact Cylinders | Brand: AIRTAC | Series: ACQJ32~40 （Note: Technical terms refined for industry context, including "precision-honed," "alignment stability," and "proximity sensor grooves" to emphasize performance characteristics. HTML line breaks preserved with improved punctuation consistency.）
AirTAC ACQJ32X100-50S Adjustable Compact Cylinder Specifications
- Model Series: ACQJ32~40 (32mm/40mm bore size)
- Full Model: ACQJ32X100-50S
- Bore Size: 32mm
- Stroke: 100mm (adjustable via external stopper)
- Operating Pressure: 0.15–0.8 MPa
- Cushioning: Adjustable pneumatic cushion (dual-side)
- Mounting: Front/rear flange (MF1/MF2) or foot mounting (MP2)
- Port Size: M5x0.8 (standard) / G1/8 optional
- Operating Temperature: -10℃ to 80℃
- Piston Speed: 50–800 mm/s
- Seal Material: NBR (nitrile rubber)
- Piston Rod Material: Hard chrome-plated steel
- Weight: 0.92 kg (without accessories)
- Dimensions (L×W×H): 200mm × 62mm × 62mm (at full extension)
- Rod Thread: M10x1.25 (external)
- Protection Class: IP54 (standard)
Ultra-slim profile cylinder (only 25mm height) with space-saving design for constrained installations. Features an external stroke adjustment mechanism with ±3mm fine-tuning capability. Dual magnetic sensors can be installed via T-slot. Compatible with Auto Switch models: D-A93/D-C73.
Typical Applications:
- PCB handling robots in electronics manufacturing
- Precision clamping fixtures for CNC machining
- Vertical lift mechanisms in packaging lines
- Medical device positioning systems
- Automated conveyor gate controls
Installation tip:
For horizontal mounting, use 70% of maximum thrust capacity. Lubricate with ISO VG32 hydraulic oil
if operating below -5℃. Allow 5mm clearance around cylinder body for heat dissipation.
Critical note:
Do NOT exceed 1,000,000 cycles without re-lubrication. Avoid side-load forces exceeding 30N.
Use locknuts (included) when mounting in vertical downward orientation.
| Property | Property Value |
|---|---|
| sku | ACQJ32X100-50S |
| Adjustable Stroke | <50mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 100mm |
