Airtac ACQJ32~40 Adjustable Thin-Type Cylinder ACQJ32X100-75
$58.12
Regular price
$65.62
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ACQJ32X100-75
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
ACQJ32~40 Adjustable Compact Cylinder
1. Complies with JIS standards.
2. Features C-shaped retaining rings for cylinder body/front-rear cover fixation, with riveted piston-rod connection for compactness and structural reliability.
3. Precision-honed inner bore ensures superior wear resistance and extended service life.
4. Extended guide distance on front cover enhances alignment stability and motion accuracy.
5. Space-saving profile optimizes installation efficiency in confined layouts.
6. Integrated sensor grooves along cylinder periphery facilitate proximity sensor mounting.
7. Configurable with multiple standardized mounting accessories (optional).
Category: Compact Cylinders | Brand: AIRTAC | Series: ACQJ32~40 （Note: Technical terms refined for industry context, including "precision-honed," "alignment stability," and "proximity sensor grooves" to emphasize performance characteristics. HTML line breaks preserved with improved punctuation consistency.）
Installation notes:
Always align cylinder axis with motion direction. Use flexible couplings when mounting to prevent side load.
Adjust cushion screws gradually (1/4 turn increments) while testing. Lubricate every 500km stroke travel
using ISO VG32 hydraulic oil. Avoid continuous operation above 0.6MPa for longevity.
2. Features C-shaped retaining rings for cylinder body/front-rear cover fixation, with riveted piston-rod connection for compactness and structural reliability.
3. Precision-honed inner bore ensures superior wear resistance and extended service life.
4. Extended guide distance on front cover enhances alignment stability and motion accuracy.
5. Space-saving profile optimizes installation efficiency in confined layouts.
6. Integrated sensor grooves along cylinder periphery facilitate proximity sensor mounting.
7. Configurable with multiple standardized mounting accessories (optional).
Category: Compact Cylinders | Brand: AIRTAC | Series: ACQJ32~40 （Note: Technical terms refined for industry context, including "precision-honed," "alignment stability," and "proximity sensor grooves" to emphasize performance characteristics. HTML line breaks preserved with improved punctuation consistency.）
AirTAC ACQJ32X100-75 Adjustable Compact Cylinder Specifications
- Series: ACQJ32~40 Thin-Type Adjustable Cylinder
- Bore size: 32mm (ACQJ32)
- Stroke: 100mm (±0.5mm tolerance)
- Mounting style: Front flange (MF1) / Rear flange (MF2)
- Operating pressure: 0.15–0.8 MPa
- Cushioning type: Rubber buffer + external adjustable stroke
- Adjustment range: 75% of total stroke (75mm adjustment limit for 100mm stroke)
- Port size: G1/8 (Rc1/8 optional)
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Chrome-plated steel (Cr12MoV)
- Seal material: NBR (Nitrile rubber) standard
- Temperature range: -20℃ to 80℃
- Weight: 1.2kg (excluding accessories)
- Dimensions: 100mm(L) × 32mm(W) × 32mm(H) (Basic length without rod extension)
- Rod end thread: M10×1.25 (Standard)
- Max theoretical force: 245N @0.5MPa
- Lubrication: Pre-lubricated (Grease packed)
Ultra-slim profile cylinder (only 32mm height) with mechanical stroke adjustment mechanism, featuring dual-position locking screws for precise stroke limitation. The double-acting design incorporates wear-resistant guide bushings and integrated magnet for position sensing compatibility. Optimized for high-cycle applications requiring space-saving solutions.
Typical Applications:
- Precision positioning in robotic pick-and-place systems
- Clamping mechanisms in semiconductor wafer handling
- Actuation in automated packaging lines with limited vertical clearance
- Medical device assembly requiring contamination-resistant components
- High-speed sorting gates in logistics automation
Installation notes:
Always align cylinder axis with motion direction. Use flexible couplings when mounting to prevent side load.
Adjust cushion screws gradually (1/4 turn increments) while testing. Lubricate every 500km stroke travel
using ISO VG32 hydraulic oil. Avoid continuous operation above 0.6MPa for longevity.
Critical parameters:
- Max piston speed: 500mm/s (with cushioning)
- Minimum operating pressure: 0.1MPa (with reduced force)
- Repeat positioning accuracy: ±0.2mm (under controlled conditions)
- Max lateral load capacity: 15N at rod end
| Property | Property Value |
|---|---|
| sku | ACQJ32X100-75 |
| Adjustable Stroke | 75mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 100mm |
