Airtac ACQJ80-100 Adjustable Compact Cylinder ACQJ100X10-10
$130.70
Regular price
$138.20
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ACQJ100X10-10
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
ACQJ80~100 Adjustable Slim Cylinder
1. Compliant with JIS industrial standards;
2. C-shaped retaining ring secures cylinder body with front/rear covers; Integrated riveted piston-rod structure ensures compactness and reliability;
3. Cylinder bore features precision honing for enhanced wear resistance and long service life;
4. Extended guide length on front cover delivers superior guiding performance;
5. Space-saving compact design optimizes installation in confined areas;
6. Perimeter sensor grooves enable hassle-free proximity sensor mounting;
7. Multiple standardized mounting accessories available for flexible configurations;
Category: Slim Cylinder | Brand: AIRTAC | Series: ACQJ80~100
Installation note:
Use alignment jigs during mounting to ensure parallelism (Max 0.2mm deviation).
For vertical installations, apply 2 drops of ISO VG32 turbine oil monthly through air port.
2. C-shaped retaining ring secures cylinder body with front/rear covers; Integrated riveted piston-rod structure ensures compactness and reliability;
3. Cylinder bore features precision honing for enhanced wear resistance and long service life;
4. Extended guide length on front cover delivers superior guiding performance;
5. Space-saving compact design optimizes installation in confined areas;
6. Perimeter sensor grooves enable hassle-free proximity sensor mounting;
7. Multiple standardized mounting accessories available for flexible configurations;
Category: Slim Cylinder | Brand: AIRTAC | Series: ACQJ80~100
AirTAC ACQJ100X10-10 Adjustable Thin Cylinder Specifications
- Series: ACQJ80~100 (Standard adjustable thin cylinder series)
- Model: ACQJ100X10-10
- Bore size: Ø100mm (±0.5mm tolerance)
- Stroke: 10mm (Adjustable ±0.5mm via built-in stopper)
- Operating pressure: 0.1~0.8 MPa
- Temperature range: -20℃~80℃ (Dry air required below 0℃)
- Cushion type: Fixed rubber buffer + adjustable air cushion
- Port size: M5x0.8 (Standard), G1/8 optional
- Mounting style: Front flange (MF1) with 4xM5x0.8 threaded holes
- Rod end: M10x1.25 external thread (ISO Standards)
- Cylinder tube material: Aluminum alloy AL6061-T6 anodized
- Seal material: NBR (Nitrile rubber) standard, optional FKM
- Weight: 2.8kg ±3% (Without accessories)
- Dimensions: 180mm(L) × 118mm(W) × 108mm(H)
- Piston speed: 50~800mm/s (Lubricated operation)
- Protection rating: IP54 (Standard), IP67 with optional kit
Ultra-flat cylinder (Only 108mm height) designed for space-constrained automation systems. Features dual-cushion design with external adjustment screws for precise stroke termination control. The reinforced flange mounting withstands 20% higher lateral loads compared to standard cylinders.
Typical Applications:
- High-density robotic palletizing systems
- Semiconductor wafer handling equipment
- Medical device clamping mechanisms
- Automotive welding fixture positioning
- Food packaging machine stoppers
Installation note:
Use alignment jigs during mounting to ensure parallelism (Max 0.2mm deviation).
For vertical installations, apply 2 drops of ISO VG32 turbine oil monthly through air port.
Critical parameters:
- Max side load: 150N at full extension
- Lubrication interval: 6 months/500km stroke (Whichever first)
- Replacement cycle: 3,000km stroke or 10 million cycles
| Property | Property Value |
|---|---|
| sku | ACQJ100X10-10 |
| Adjustable Stroke | <10mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | <10mm> |
