Airtac ACQJ80-100 Adjustable Compact Cylinder ACQJ100X10-10S
2. C-shaped retaining ring secures cylinder body with front/rear covers; Integrated riveted piston-rod structure ensures compactness and reliability;
3. Cylinder bore features precision honing for enhanced wear resistance and long service life;
4. Extended guide length on front cover delivers superior guiding performance;
5. Space-saving compact design optimizes installation in confined areas;
6. Perimeter sensor grooves enable hassle-free proximity sensor mounting;
7. Multiple standardized mounting accessories available for flexible configurations;
Category: Slim Cylinder | Brand: AIRTAC | Series: ACQJ80~100
AirTAC ACQJ100X10-10S Adjustable Compact Cylinder Specifications
- Series: ACQJ80~100 (80/100mm bore size range)
- Model: ACQJ100X10-10S
- Bore size: 100mm
- Stroke: 10mm (adjustable cushion)
- Mounting type: Basic type (MF1 mounting standard)
- Buffer adjustment: External adjustable cushioning
- Piston speed: 50-800mm/s
- Operating pressure: 0.1-0.9 MPa
- Temperature range: -20℃ to 80℃
- Port size: 1/4" NPT (G1/8 optional)
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Chrome-plated steel
- Seal type: NBR rubber seals
- Weight: 2.5kg (without accessories)
- Dimensions: 152mm(L) × 110mm(W) × 110mm(H)
- Stroke tolerance: ±1.5mm
- Repeat accuracy: ±0.5mm
- Air consumption: 7.85L per cycle @0.6MPa
Ultra-slim profile cylinder featuring external cushion adjustment screws for precise end-position damping control. The nickel-plated rod and self-lubricating bearings ensure smooth operation in high-cycle applications. Integrated mounting slots allow direct installation without additional brackets.
- Space-constrained clamping fixtures
- Precision alignment mechanisms in PCB assembly
- Vertical lifting systems in packaging lines
- Quick-stroke positioning in automated test equipment
- Medical device actuation requiring smooth stops
Operation tip:
For optimal cushioning performance, adjust the needle valves gradually while observing piston motion.
Always complete 5-10 test cycles after adjustment. Lubricate through air supply (ISO VG32 recommended).
| Property | Property Value |
|---|---|
| sku | ACQJ100X10-10S |
| Adjustable Stroke | <10mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | <10mm> |
