Airtac ACQJ80-100 Adjustable Compact Cylinder ACQJ100X10-10SB
2. C-shaped retaining ring secures cylinder body with front/rear covers; Integrated riveted piston-rod structure ensures compactness and reliability;
3. Cylinder bore features precision honing for enhanced wear resistance and long service life;
4. Extended guide length on front cover delivers superior guiding performance;
5. Space-saving compact design optimizes installation in confined areas;
6. Perimeter sensor grooves enable hassle-free proximity sensor mounting;
7. Multiple standardized mounting accessories available for flexible configurations;
Category: Slim Cylinder | Brand: AIRTAC | Series: ACQJ80~100
AirTAC ACQJ80~100 Adjustable Thin Cylinder ACQJ100X10-10SB Technical Details
- Series: ACQJ (Adjustable Compact Cylinder)
- Full model: ACQJ100X10-10SB
- Bore size: 100mm
- Stroke: 10mm (adjustable with ±0.5mm precision)
- Operating pressure: 0.1-0.8 MPa
- Port size: M5x0.8 (standard) / NPT1/8 optional
- Cushioning: Adjustable air cushion at both ends
- Mounting type: Basic foot mounting (ISO 15552 standard)
- Temperature range: -20℃ to 80℃
- Seal material: NBR (Nitrile rubber) / PU optional
- Piston speed: 50-700 mm/s
- Protection rating: IP40 (IP67 with optional wiper)
- Weight: 1.3kg (excluding accessories)
- Dimensions: 155mm(L) × 100mm(W) × 30mm(H)
Ultra-flat cylinder (height ≤30mm) with precision stroke adjustment capability through integrated micrometer mechanism. Features dual anti-rotation guide rods and hard chrome-plated piston rod (hardness ≥800HV). The SB suffix indicates special brass end fittings for enhanced corrosion resistance.
- High-density automated assembly lines requiring space optimization
- Precision press-fit operations in electronics manufacturing
- Clamping fixtures for CNC machining centers
- Packaging machinery with vertical space constraints
- Medical device positioning systems requiring smooth motion
Installation Guidelines:1. Maintain lateral clearance ≥5mm for heat dissipation
2. Perform dynamic load calculation when stroke exceeds 50mm
3. Apply ISO VG32 hydraulic oil lubrication for operations below -10℃
4. Recommended maintenance cycle: 5 million strokes or 12 months
| Property | Property Value |
|---|---|
| sku | ACQJ100X10-10SB |
| Adjustable Stroke | <10mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | <10mm> |
