Airtac ACQJ80-100 Adjustable Compact Cylinder ACQJ100X100-10
2. C-shaped retaining ring secures cylinder body with front/rear covers; Integrated riveted piston-rod structure ensures compactness and reliability;
3. Cylinder bore features precision honing for enhanced wear resistance and long service life;
4. Extended guide length on front cover delivers superior guiding performance;
5. Space-saving compact design optimizes installation in confined areas;
6. Perimeter sensor grooves enable hassle-free proximity sensor mounting;
7. Multiple standardized mounting accessories available for flexible configurations;
Category: Slim Cylinder | Brand: AIRTAC | Series: ACQJ80~100
AirTAC ACQJ100X100-10 Adjustable Slim Cylinder Specifications
- Series: ACQJ80~100 (Adjustable Compact Cylinder Series)
- Bore size: 100mm
- Stroke: 100mm (adjustable)
- Operating pressure: 0.1~0.9 MPa
- Temperature range: -20℃ to 80℃
- Port size: PT1/4 (G1/4 optional)
- Cushion type: Adjustable pneumatic cushion (10mm buffer length)
- Piston speed: 50~800 mm/s
- Mounting type: Basic type (MF1) with multiple mounting options
- Rod end: Female thread M16×1.5
- Seal material: NBR (Nitrile Butadiene Rubber)
- Body material: Anodized aluminum alloy
- Weight: 2.5kg ±3%
- Dimensions: 220mm(L) × 140mm(W) × 100mm(H)
- ISO standard: ISO 6432 compliant
- Protection rating: IP65 (rod extended)
Ultra-flat cylinder (only 100mm height) with precision adjustable stroke mechanism, featuring dual adjustable cushions for shock absorption. The low-profile design integrates T-slot mounting grooves for flexible installation. Requires 5μm filtered air with ISO 8573-1:2010 class 4.4.3 air quality.
- High-speed pick-and-place systems in electronics assembly
- Clamping mechanisms in CNC machining centers
- Vertical lift systems in automated packaging lines
- Precision positioning in semiconductor handling equipment
- Compact press mechanisms in automotive component assembly
Installation note:
Lubricate rod with ISO VG32 hydraulic oil before initial use.
Maintain 0.5mm minimum clearance between rod and adjacent components.
For vertical mounting, install air vent plug at upper port.
| Property | Property Value |
|---|---|
| sku | ACQJ100X100-10 |
| Adjustable Stroke | <10mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | 100mm |
