AirTAC ACQJ Series · JIS Compact Adjustable-Stroke Cylinder

Airtac ACQJ80-100 Adjustable Compact Cylinder ACQJ100X100-100B

The AirTAC ACQJ80-100 Adjustable Compact Cylinder ACQJ100X100-100B is a genuine double-acting COMPACT (JIS) cylinder with an EXTERNAL adjustable stop on the extend stroke — a Ø100mm bore and 100mm full stroke. Turn the stop to fine-tune the end position on the machine without changing parts.

  • BoreØ100 mm
  • Full stroke100 mm
  • Port sizePT3/8
  • Adjuster threadM27×2.0
$189.59 $197.09Save 3% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every ACQJ100 stroke, mounting and version on one page All ACQJ100 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac ACQJ80-100 Adjustable Compact Cylinder ACQJ100X100-100B

The AirTAC ACQJ100X100-100B is a double-acting JIS compact cylinder with a 100mm bore and a male-thread piston rod end (M26x1.5). An external threaded stop with a lock nut limits the EXTEND end position. The usable extend range runs from 0mm up to the full 100mm stroke. The RETRACT stroke remains unaffected.

Because the piston area is unchanged, the force is identical to a standard ACQ of this bore. The push force is 3927N at 0.5MPa (5497.8N at 0.7MPa, max 801kgf at 1.0MPa) and the pull force is 3524.8N at 0.5MPa. The body features a fixed elastomer bumper at each end and includes magnetic-switch grooves, though this specific model ships without a magnet. The port size is PT3/8.

Airtac ACQJ80-100 Adjustable Compact Cylinder ACQJ100X100-100B Technical Specifications

ModelAirtac ACQJ80-100 Adjustable Compact Cylinder ACQJ100X100-100B
SeriesACQJ JIS compact adjustable-stroke cylinder
Bore sizeØ100 mm
Full stroke100 mm
Adjuster threadM27×2.0
Port sizePT3/8
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 500 mm/s
Rod threadM20×2.5 (F) / M26×1.5 (B)

Specifications follow the official AirTAC ACQJ datasheet. The adjustable stop shortens the EXTEND stroke only; ACQJ is double-rod, so push is lower than a standard ACQ of this bore. Adjustable window options: 10/20/30/40/50/75/100 mm.

Theoretical Output Force (Ø100mm)

PressurePush forcePull force
0.5 MPa3525 N3525 N
0.7 MPa4935 N—
Max (@1.0 MPa)719 kgf

ACQJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod ACQ push of the same bore. Actual usable force is lower due to friction; size with a safety margin.

Model Code: Airtac ACQJ80-100 Adjustable Compact Cylinder ACQJ100X100-100B

ACQJJIS compact double-acting ADJUSTABLE-STROKE cylinder series.
100Bore size in mm.
×100Full stroke length in mm.
-0Adjustable window in mm (extend stroke can be shortened by up to this).
S / BMagnet (S) / male-thread rod (B); omit for none / female thread.

Thread: PT standard (G / NPT available). Related: ACQ (fixed stroke), ACQD (double rod), TACQ (guided / non-rotating).

Where the Airtac ACQJ80-100 Adjustable Compact Cylinder ACQJ100X100-100B Is Used

precision_manufacturing

Press Tonnage Trials

Dial in exact pressing depth on a 100mm bore assembly during prototype testing, using the external stop to test multiple end positions without machining new spacers.

view_module

Multi-Part Changeover

Switch between two product heights on a single conveyor line by turning the M27x2.0 adjuster screw to shorten the extend stroke from 100mm down to 0mm.

package_2

Variable Depth Flap Folding

Accommodate different carton sizes on a packaging machine by tuning the extend end position on the fly, while the fixed bumper absorbs the stopping energy.

Is the Airtac ACQJ80-100 Adjustable Compact Cylinder ACQJ100X100-100B the Right Cylinder?

A fixed-stroke ACQ is sufficient if your end position never requires adjustment. When ordering, confirm the 100mm bore, 100mm full stroke, 100mm adjustment window, the male rod thread, and note that the -S magnet is absent here.

AirtacDistr lists every ACQJ100 order code with its price on one page at https://airtacdistr.com/products/airtac-acqj100-adjustable-cylinder

Quick checklist

  • ✓ Need on-machine end-position tuning?
  • ✓ Full stroke and adjust window (mm)
  • ✓ Force at your working pressure
  • ✓ Magnet (S) for sensors?
  • ✓ Female (blank) or male (B) rod thread
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Lock the adjuster nut after setting the stop.
  • check The stop limits the EXTEND stroke only.
  • check Avoid side load on the short piston rod.
  • check Installation by qualified personnel per AirTAC docs.

Airtac ACQJ80-100 Adjustable Compact Cylinder ACQJ100X100-100B FAQ

The usable extend range is 0-100mm (full stroke 100mm minus a 100mm window). The force is identical to a standard ACQ: push is 3927N and pull is 3524.8N at 0.5MPa, push is 5497.8N at 0.7MPa, and max push is 801kgf at 1.0MPa.

The external M27x2.0 threaded stop with lock nut limits only the extend stroke length; it does not change piston area, so force is unchanged. The retract stroke is unaffected. The cylinder uses a fixed elastomer bumper at each end, not an adjustable air cushion. Note that a plain ACQ does not hold its load on air loss; use an external rod lock for fail-safe holding.
