Airtac ACQJ80-100 Adjustable Compact Cylinder ACQJ100X100-100SB
2. C-shaped retaining ring secures cylinder body with front/rear covers; Integrated riveted piston-rod structure ensures compactness and reliability;
3. Cylinder bore features precision honing for enhanced wear resistance and long service life;
4. Extended guide length on front cover delivers superior guiding performance;
5. Space-saving compact design optimizes installation in confined areas;
6. Perimeter sensor grooves enable hassle-free proximity sensor mounting;
7. Multiple standardized mounting accessories available for flexible configurations;
Category: Slim Cylinder | Brand: AIRTAC | Series: ACQJ80~100
AirTAC ACQJ80~100 Adjustable Compact Cylinder ACQJ100X100-100SB Specifications
- Model: ACQJ100X100-100SB
- Series: ACQJ80~100 adjustable thin-type cylinder
- Bore size: 100mm
- Stroke: 100mm (±1mm adjustable)
- Mounting type: Adjustable thin-type bracket (integral design)
- Adjustment method: External mechanical stopper with locknut
- Operating pressure: 0.1–0.8 MPa (14.5–116 psi)
- Cushioning: Rubber buffer (both ends)
- Port size: G1/2 (ISO228/1 standard)
- Piston rod thread: M20×1.5
- Material:
- Cylinder tube: Aluminum alloy (hard anodized)
- End covers: Die-cast aluminum alloy
- Piston rod: Hard chrome-plated steel (HRC 45-50)
- Seal material: NBR (nitrile rubber)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Protection rating: IP40
- Weight: 2.8kg (6.17 lbs) ±3%
- Dimensions:
- Total length: 270mm (at mid-stroke)
- Width: 125mm (mounting bracket included)
- Height: 100mm (cylinder body diameter)
Ultra-slim profile cylinder (25% thinner than standard models) with precision stroke adjustment capability. Features corrosion-resistant construction and double-acting operation. The hardened piston rod and metal end covers enable high side load capacity (up to 300N lateral force). Includes built-in auto-lubrication design for maintenance-free operation under normal conditions.
- Space-constrained automation equipment
- Precision clamping fixtures in CNC machines
- Packaging line product positioning gates
- Material handling lift-stop mechanisms
- Automotive assembly jig actuators
Usage note:
Lubricate with ISO VG32 hydraulic oil before initial use.
For adjustable stroke applications, tighten locknut to 5-7 N·m torque after positioning.
Maintain vertical mounting orientation for optimal wear distribution.
Ensure rod-end load alignment within ±2° angular tolerance.
| Property | Property Value |
|---|---|
| sku | ACQJ100X100-100SB |
| Adjustable Stroke | 100mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 100mm |
