Airtac ACQJ80-100 Adjustable Compact Cylinder ACQJ100X100-10S
2. C-shaped retaining ring secures cylinder body with front/rear covers; Integrated riveted piston-rod structure ensures compactness and reliability;
3. Cylinder bore features precision honing for enhanced wear resistance and long service life;
4. Extended guide length on front cover delivers superior guiding performance;
5. Space-saving compact design optimizes installation in confined areas;
6. Perimeter sensor grooves enable hassle-free proximity sensor mounting;
7. Multiple standardized mounting accessories available for flexible configurations;
Category: Slim Cylinder | Brand: AIRTAC | Series: ACQJ80~100
AirTAC ACQJ Series Adjustable Compact Cylinder ACQJ100X100-10S Specifications
- Model: ACQJ100X100-10S
- Series: ACQJ80~100 (Adjustable Thin Type)
- Bore size: 100mm
- Stroke: 100mm
- Operation: Double-acting
- Mounting style: Basic type (Standard)
- Adjustable cushioning: Front & rear stroke adjustment
- Port size: G1/8 (ISO standard thread)
- Operating pressure: 0.1~0.9 MPa
- Ambient temperature: -20℃ to +80℃
- Piston speed: 50~1000 mm/s
- Piston rod material: Stainless steel (SUS304)
- Tube material: Aluminum alloy (Hard anodized)
- Seal material: NBR (Nitrile rubber)
- Weight: 3.5 kg (including accessories)
- Dimensions: 200mm(L) × 100mm(W) × 100mm(H) (Stroke extended)
- Rod end type: Female thread M10×1.25
- Protection class: IP65 (Dust & water jet resistant)
- Air consumption: 785 cm³/stroke @ 0.5MPa
Ultra-slim profile cylinder (30% thinner than standard models) with precision-adjustable cushioning mechanism. Features double O-ring rod seals for enhanced leak protection and chrome-plated piston rod for corrosion resistance. The compact design integrates mounting grooves for space-efficient installation in confined areas. Requires ISO 8573-1 class 3 lubricated or non-lubricated air.
- High-density automation cells in electronics assembly
- Vertical actuation in packaging machinery
- Precision clamping fixtures for CNC machining
- Material transfer systems with limited vertical clearance
- Cleanroom-compatible medical device actuators
Installation note:
Maintain parallel alignment during mounting - maximum allowable angular error ≤0.5°. Use locknuts (included) for vibration resistance.
Cushion adjustment procedure: Turn clockwise to soften cushioning, counter-clockwise to strengthen (1/4 turn increments recommended).
| Property | Property Value |
|---|---|
| sku | ACQJ100X100-10S |
| Adjustable Stroke | <10mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 100mm |
