Airtac ACQJ80-100 Adjustable Compact Cylinder ACQJ100X100-10SB
2. C-shaped retaining ring secures cylinder body with front/rear covers; Integrated riveted piston-rod structure ensures compactness and reliability;
3. Cylinder bore features precision honing for enhanced wear resistance and long service life;
4. Extended guide length on front cover delivers superior guiding performance;
5. Space-saving compact design optimizes installation in confined areas;
6. Perimeter sensor grooves enable hassle-free proximity sensor mounting;
7. Multiple standardized mounting accessories available for flexible configurations;
Category: Slim Cylinder | Brand: AIRTAC | Series: ACQJ80~100
AirTAC ACQJ100X100-10SB Adjustable Compact Cylinder Specifications
- Model Series: ACQJ80~100 (specific model: ACQJ100X100-10SB)
- Type: Adjustable stroke thin-series pneumatic cylinder
- Bore size: Ø100mm (ISO 6432 standard)
- Stroke: 100mm (adjustable through external stopper)
- Operating pressure: 0.05~1.0 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: External adjustable rubber bumper
- Mounting style: Basic type (MF1) with front flange
- Port size: Rc1/4 (NPT1/4 optional)
- Piston rod thread: M20×1.5
- Weight: 2.3kg (excluding accessories)
- Dimensions:
- Length: 212mm (min. retracted length)
- Width: 130mm (flange mounting base)
- Height: 118mm (cylinder body diameter)
- Seal material: High-grade NBR + Special wear-resistant ring
- Protection rating: IP54 (standard), IP67 available with optional wiper
- Lubrication: Pre-lubricated (Oil-free operation possible)
Ultra-flat cylinder (only 30% height of standard cylinders) with space-saving design for modern automation systems. Features precision-machined anodized aluminum barrel and chromium-plated piston rod. The -10SB variant includes magnetic piston for position sensing compatibility. Dual cushion adjustment screws allow precise end-position control without disassembly.
- High-density modular assembly lines
- Robotic welding fixture clamping
- Semiconductor wafer handling systems
- Vertical injection molding ejectors
- Elevator door locking mechanisms
Installation tips:
Maintain 0.5mm minimum clearance between rod end and load during alignment.
For vertical mounting, use model suffix with "V" (not included in standard -10SB).
Lubricate rod weekly in high-cycle applications (>500,000 cycles/year).
| Property | Property Value |
|---|---|
| sku | ACQJ100X100-10SB |
| Adjustable Stroke | <10mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 100mm |
