Airtac ACQJ80-100 Adjustable Compact Cylinder ACQJ100X100-20
2. C-shaped retaining ring secures cylinder body with front/rear covers; Integrated riveted piston-rod structure ensures compactness and reliability;
3. Cylinder bore features precision honing for enhanced wear resistance and long service life;
4. Extended guide length on front cover delivers superior guiding performance;
5. Space-saving compact design optimizes installation in confined areas;
6. Perimeter sensor grooves enable hassle-free proximity sensor mounting;
7. Multiple standardized mounting accessories available for flexible configurations;
Category: Slim Cylinder | Brand: AIRTAC | Series: ACQJ80~100
AirTAC ACQJ100X100-20 Adjustable Compact Cylinder Specifications
- Series: ACQJ80~100 Thin Type
- Model: ACQJ100X100-20
- Bore size: 100mm
- Stroke: 100mm (±0.5mm adjustment range)
- Mounting type: Front flange (MF1) with tapped mounting holes
- Operating pressure: 0.1–0.8 MPa
- Cushioning: Adjustable pneumatic cushion (5mm adjustment)
- Port size: G3/8 (NPT1/4 optional)
- Temperature range: -20℃ to 80℃
- Piston speed: 50–800 mm/s
- Seal material: NBR (Nitrile rubber)
- Cylinder body: Aluminum alloy (hard anodized)
- Rod material: Stainless steel SUS304
- Weight: 3.2kg ±5% (without accessories)
- Dimensions: 192mm(L) × 100mm(Bore diameter) × 44mm(H) (flange face to rod end)
- Rod thread: M16×1.5
- Protection rating: IP54 (standard wiper seal)
- Lubrication: Pre-lubricated (Use ISO VG32 turbine oil if re-lubrication required)
Ultra-flat cylinder with space-saving design (30% thinner than standard cylinders), featuring dual adjustable cushioning screws for precise end-position deceleration control. The anodized aluminum construction provides corrosion resistance in humid environments. Integrated mounting grooves allow direct sensor installation without brackets.
- High-speed pick-and-place systems in electronics assembly
- Clamping fixtures for CNC machining centers
- Vertical lift mechanisms in packaging machinery
- Automated door operators in cleanroom environments
- Material handling robots in automotive production lines
Installation note:
Maintain 0.5mm minimum clearance between cylinder body and adjacent components for heat dissipation.
Use locknuts (not included) for stroke adjustment screws after positioning. Lubricate rod with silicone grease
monthly in high-cycle applications (>500,000 cycles/year).
| Property | Property Value |
|---|---|
| sku | ACQJ100X100-20 |
| Adjustable Stroke | <20mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | 100mm |
