Airtac ACQJ80-100 Adjustable Compact Cylinder ACQJ100X100-20B
2. C-shaped retaining ring secures cylinder body with front/rear covers; Integrated riveted piston-rod structure ensures compactness and reliability;
3. Cylinder bore features precision honing for enhanced wear resistance and long service life;
4. Extended guide length on front cover delivers superior guiding performance;
5. Space-saving compact design optimizes installation in confined areas;
6. Perimeter sensor grooves enable hassle-free proximity sensor mounting;
7. Multiple standardized mounting accessories available for flexible configurations;
Category: Slim Cylinder | Brand: AIRTAC | Series: ACQJ80~100
AirTAC ACQJ100X100-20B Adjustable Compact Cylinder Specifications
- Series: ACQJ80~100 (Compact Adjustable Stroke)
- Model: ACQJ100X100-20B
- Bore size: Φ100mm
- Stroke: 100mm (Adjustable range: 0-20mm)
- Mounting type: Basic (Standard flange)
- Operating pressure: 0.05~0.8 MPa
- Cushioning: Fixed buffer + Adjustable stroke mechanism
- Port size: G3/8 (Standard), optional NPT1/2
- Temperature range: -20℃ to 80℃
- Rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR + PU combination
- Weight: 2.8kg (Excluding accessories)
- Dimensions:
- Length: 233mm (Min) / 333mm (Max extended)
- Width: 128mm (Flange mounting base)
- Height: 128mm (Square body profile)
- Lubrication: Pre-lubricated (Relubrication interval: 2000km)
Ultra-flat cylinder (25% thinner than standard models) with integrated stroke adjustment mechanism. Features dual anti-rotation guide rods and corrosion-resistant construction. The built-in locknut enables precise stroke positioning (±0.5mm repeatability). Compatible with magnetic sensors for position feedback (Sensor slot: 8mm width).
- Precision clamping in CNC fixture systems
- Material feeding mechanisms with space constraints
- Printing press paper handling units
- Automated assembly line positioning stages
- Packaging machine product ejection systems
Installation note:
Mounting surface flatness ≤0.1mm. Use M6 mounting screws (Torque: 4.5±0.5N·m).
For adjustable stroke operation: Loosen locknut → Set position → Retighten with 1.2-1.5N·m torque.
| Property | Property Value |
|---|---|
| sku | ACQJ100X100-20B |
| Adjustable Stroke | <20mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | 100mm |
