Airtac ACQJ80-100 Adjustable Compact Cylinder ACQJ100X100-20S
2. C-shaped retaining ring secures cylinder body with front/rear covers; Integrated riveted piston-rod structure ensures compactness and reliability;
3. Cylinder bore features precision honing for enhanced wear resistance and long service life;
4. Extended guide length on front cover delivers superior guiding performance;
5. Space-saving compact design optimizes installation in confined areas;
6. Perimeter sensor grooves enable hassle-free proximity sensor mounting;
7. Multiple standardized mounting accessories available for flexible configurations;
Category: Slim Cylinder | Brand: AIRTAC | Series: ACQJ80~100
AirTAC ACQJ100X100-20S Adjustable Compact Cylinder Specifications
- Series: ACQJ80~100 (Adjustable Cushioning Thin Cylinder Series)
- Model: ACQJ100X100-20S
- Bore size: 100mm
- Stroke: 100mm
- Operating pressure: 0.05-1.0 MPa
- Ambient temperature: -20℃ to 80℃
- Cushioning type: Adjustable buffer (both ends)
- Piston rod thread: M20×1.5
- Mounting type: 20S (Swivel foot with fixed bolt)
- Port size: G3/8
- Material: Aluminum alloy cylinder tube, carbon steel piston rod
- Seal material: NBR
- Weight: ~3.8kg
- Dimensions: 290mm(L) × 100mm(Bore diameter) × 128mm(H) (including mounting accessories)
- Protection rating: IP40
- Piston speed: 50-750mm/s
- Theoretical output: 785N at 0.63MPa (extend side)
Ultra-flat cylinder (height reduced by 30% vs standard models) with space-saving design for confined installations. Features dual adjustable air cushions for precise end-position damping control. Precision honed inner tube ensures ≤0.5mm/m straightness tolerance. Integrated wear-resistant band extends service life to 5,000km under standard conditions.
- Press machine ejection systems
- Automated palletizing robot end-effectors
- Semiconductor wafer handling equipment
- Injection molding machine core-pulling mechanisms
- Automotive welding fixture positioning
Installation protocol:
Lubricate rod with ISO VG32 hydraulic oil before initial use.
Maintain 0.5mm minimum parallel alignment tolerance between rod and load.
Requires 0.3μm precision filter for optimal performance.
| Property | Property Value |
|---|---|
| sku | ACQJ100X100-20S |
| Adjustable Stroke | <20mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 100mm |
