Airtac ACQJ80-100 Adjustable Compact Cylinder ACQJ100X100-20SB
2. C-shaped retaining ring secures cylinder body with front/rear covers; Integrated riveted piston-rod structure ensures compactness and reliability;
3. Cylinder bore features precision honing for enhanced wear resistance and long service life;
4. Extended guide length on front cover delivers superior guiding performance;
5. Space-saving compact design optimizes installation in confined areas;
6. Perimeter sensor grooves enable hassle-free proximity sensor mounting;
7. Multiple standardized mounting accessories available for flexible configurations;
Category: Slim Cylinder | Brand: AIRTAC | Series: ACQJ80~100
AirTAC ACQJ100X100-20SB Adjustable Compact Cylinder Specifications
- Series: ACQJ80~100 Thin-Type Adjustable
- Full model: ACQJ100X100-20SB
- Bore size: 100mm
- Stroke: 100mm (±5mm adjustable)
- Operating pressure: 0.05~0.9 MPa
- Piston speed: 50~800 mm/s
- Mounting type: Basic (with adjustable stopper)
- Cushioning: Rubber buffer + adjustable screw
- Port size: G3/8 (NPT1/2 optional)
- Ambient temperature: -20℃ to 80℃
- Rod material: Hard chrome-plated steel
- Tube material: Aluminum alloy (anodized)
- Seal material: NBR (HNBR available for high temp)
- Weight: 1.85kg (without accessories)
- Dimensions:
- Body length: 182mm (standard stroke)
- Width: 124mm (mounting bracket included)
- Height: 124mm (square cross-section)
Ultra-low profile cylinder with integrated stroke adjustment mechanism, featuring 360° rotatable auto-lubricating bearing for precise positioning. The 20SB variant includes dual magnetic sensors (NPN/PNP selectable) with IP67-rated M8 connectors. Designed for applications requiring precise end-position control in confined spaces.
- Semiconductor wafer handling robots
- Automated pallet height adjustment systems
- High-speed sorting gate actuators
- Plastic injection mold clamping mechanisms
- Food packaging vertical lifters (sanitary version available)
Installation tip:
For optimal performance, maintain 0.5mm minimum clearance between adjustable stoppers during alignment.
Use M5x0.8 screws with 2.5N·m torque for mounting. Lubricate with ISO VG32 hydraulic oil during maintenance.
| Property | Property Value |
|---|---|
| sku | ACQJ100X100-20SB |
| Adjustable Stroke | <20mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 100mm |
