Airtac ACQJ80-100 Adjustable Compact Cylinder ACQJ100X100-30S
2. C-shaped retaining ring secures cylinder body with front/rear covers; Integrated riveted piston-rod structure ensures compactness and reliability;
3. Cylinder bore features precision honing for enhanced wear resistance and long service life;
4. Extended guide length on front cover delivers superior guiding performance;
5. Space-saving compact design optimizes installation in confined areas;
6. Perimeter sensor grooves enable hassle-free proximity sensor mounting;
7. Multiple standardized mounting accessories available for flexible configurations;
Category: Slim Cylinder | Brand: AIRTAC | Series: ACQJ80~100
AirTAC ACQJ100X100-30S Adjustable Compact Cylinder Specifications
- Model Series: ACQJ80~100 (Thin Type)
- Specific Model: ACQJ100X100-30S
- Bore Size: 100mm
- Stroke: 100mm (adjustable)
- Operating Pressure: 0.15–0.8 MPa
- Temperature Range: -20℃ to 80℃
- Cushioning: Rubber + External Adjuster (30S code)
- Mounting Style: Standard Foot Mount (ISO 15552 compatible)
- Port Size: PT1/4 (G1/4 optional)
- Piston Rod Thread: M20×1.5
- Material: Aluminum Alloy Body, Chrome-plated Rod
- Seal Material: NBR (Nitrile Rubber)
- Weight: ~3.8kg (without accessories)
- Dimensions: 100mm(W) × 100mm(H) × 312mm(L) (at full extension)
- Stroke Tolerance: ±1.5mm
- Max Theoretical Force: 628N @0.8MPa
Ultra-slim profile cylinder (40% thinner than standard models) with stroke micro-adjustment capability through rotating end caps. Features dual anti-rotation guides and corrosion-resistant construction. Includes magnetic piston for sensor compatibility. Requires ISO VG32 hydraulic oil mist lubrication (non-lube version available).
- Space-constrained automation lines (electronics assembly)
- Vertical lifting mechanisms in packaging machinery
- Precision press-fit operations with stroke adjustment needs
- Cleanroom applications (optional stainless steel version)
- Modular tooling systems requiring quick stroke changes
Installation Tip:
Maintain 0.5-1mm gap between cylinder and load during alignment.
For vertical mounting, use rod-down orientation. Relubricate every
500km of cumulative stroke movement. Avoid side load exceeding 15%
of maximum thrust capacity.
| Property | Property Value |
|---|---|
| sku | ACQJ100X100-30S |
| Adjustable Stroke | 30mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 100mm |
