Airtac ACQJ80-100 Adjustable Compact Cylinder ACQJ100X100-30SB
2. C-shaped retaining ring secures cylinder body with front/rear covers; Integrated riveted piston-rod structure ensures compactness and reliability;
3. Cylinder bore features precision honing for enhanced wear resistance and long service life;
4. Extended guide length on front cover delivers superior guiding performance;
5. Space-saving compact design optimizes installation in confined areas;
6. Perimeter sensor grooves enable hassle-free proximity sensor mounting;
7. Multiple standardized mounting accessories available for flexible configurations;
Category: Slim Cylinder | Brand: AIRTAC | Series: ACQJ80~100
AirTAC ACQJ80~100 Adjustable Compact Cylinder ACQJ100X100-30SB Specifications
- Model: ACQJ100X100-30SB (Range: ACQJ80~100 series)
- Type: Double-acting adjustable stroke thin cylinder
- Bore size: 100mm
- Stroke: 100mm (adjustable within 0-100mm)
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable pneumatic cushion
- Mounting style: Front flange with through holes (SB-type)
- Temperature range: -20℃ to 80℃
- Rod material: Hard chrome-plated carbon steel
- Tube material: Anodized aluminum alloy
- Port size: G3/8 (ISO standard)
- Piston speed: 50–700 mm/s
- Protection rating: IP54 (standard seals)
- Weight: 3.2 kg ±5%
- Dimensions: 202mm(L) × 118mm(W) × 118mm(H)
Ultra-slim profile cylinder (30% thinner than standard models) with stroke adjustment mechanism, featuring integrated shock absorption and dual anti-rotation guides. Precision-machined rod gland prevents leakage during high-frequency operations (up to 5 cycles/second). Includes auto-lubricating bushings for maintenance-free operation up to 2,000km travel life.
- PCB handling robots requiring space-saving actuators
- Automated packaging line clamp positioning
- Solar panel assembly presses
- Medical device testing equipment
- Elevator door locking mechanisms
Installation guidance:
For vertical mounting, use counterbalance valves when holding loads >5kg.
Lubricate pivot joints every 500,000 cycles with ISO VG32 hydraulic oil.
Avoid side load exceeding 30N·m during alignment.
| Property | Property Value |
|---|---|
| sku | ACQJ100X100-30SB |
| Adjustable Stroke | 30mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 100mm |
