Airtac ACQJ80-100 Adjustable Compact Cylinder ACQJ100X100-40
$189.59
Regular price
$197.09
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ACQJ100X100-40
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
ACQJ80~100 Adjustable Slim Cylinder
1. Compliant with JIS industrial standards;
2. C-shaped retaining ring secures cylinder body with front/rear covers; Integrated riveted piston-rod structure ensures compactness and reliability;
3. Cylinder bore features precision honing for enhanced wear resistance and long service life;
4. Extended guide length on front cover delivers superior guiding performance;
5. Space-saving compact design optimizes installation in confined areas;
6. Perimeter sensor grooves enable hassle-free proximity sensor mounting;
7. Multiple standardized mounting accessories available for flexible configurations;
Category: Slim Cylinder | Brand: AIRTAC | Series: ACQJ80~100
Installation guidance:
Maintain 0.5mm minimum clearance between cylinder body and machine structure.
Use dynamic load calculations when stroke exceeds 50% of maximum. Lubricate
rod end weekly in high-cycle applications (>500,000 cycles/year).
2. C-shaped retaining ring secures cylinder body with front/rear covers; Integrated riveted piston-rod structure ensures compactness and reliability;
3. Cylinder bore features precision honing for enhanced wear resistance and long service life;
4. Extended guide length on front cover delivers superior guiding performance;
5. Space-saving compact design optimizes installation in confined areas;
6. Perimeter sensor grooves enable hassle-free proximity sensor mounting;
7. Multiple standardized mounting accessories available for flexible configurations;
Category: Slim Cylinder | Brand: AIRTAC | Series: ACQJ80~100
AirTAC ACQJ100X100-40 Adjustable Compact Cylinder Specifications
- Model Series: ACQJ80~100
- Specific Model: ACQJ100X100-40
- Type: Adjustable stroke thin-line pneumatic cylinder
- Bore size: Ø100mm
- Stroke: 100mm (adjustable within 0-100mm)
- Operating pressure: 0.05~1.0 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion
- Mounting style: Basic type (axial mounting holes)
- Port size: M27×1.5 (standard) / NPT1-1/4 optional
- Piston material: Aluminum alloy with hard anodization
- Rod material: Chrome-plated carbon steel
- Seal type: NBR rubber seals
- Weight: 3.45kg (without accessories)
- Dimensions: 298mm(L) × 118mm(W) × 118mm(H)
- Max thrust: 785N @0.63MPa
- Lubrication: Pre-lubricated (optional oil-free operation)
- ISO standard: 6431 (alternative to ISO 15552 compact series)
Ultra-flat cylinder (38% slimmer than standard models) with stroke adjustment mechanism featuring dual locking nuts for precise positioning. The anti-rotation design maintains alignment in vertical installations. Features wear-resistant guide bands and IP67 protection rating for dusty environments.
Industrial Applications:
- Press-fit operations in automotive assembly lines
- Clamping devices for CNC machining centers
- Vertical lifting mechanisms in packaging machinery
- Position adjustment in semiconductor handling systems
- Material compression in recycling equipment
Installation guidance:
Maintain 0.5mm minimum clearance between cylinder body and machine structure.
Use dynamic load calculations when stroke exceeds 50% of maximum. Lubricate
rod end weekly in high-cycle applications (>500,000 cycles/year).
| Property | Property Value |
|---|---|
| sku | ACQJ100X100-40 |
| Adjustable Stroke | <40mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | 100mm |
