Airtac ACQJ80-100 Adjustable Compact Cylinder ACQJ100X100-40SB
2. C-shaped retaining ring secures cylinder body with front/rear covers; Integrated riveted piston-rod structure ensures compactness and reliability;
3. Cylinder bore features precision honing for enhanced wear resistance and long service life;
4. Extended guide length on front cover delivers superior guiding performance;
5. Space-saving compact design optimizes installation in confined areas;
6. Perimeter sensor grooves enable hassle-free proximity sensor mounting;
7. Multiple standardized mounting accessories available for flexible configurations;
Category: Slim Cylinder | Brand: AIRTAC | Series: ACQJ80~100
AirTAC ACQJ100X100-40SB Adjustable Thin Cylinder Specifications
- Series: ACQJ80~100 (Standard Adjustable Stroke)
- Full Model: ACQJ100X100-40SB
- Bore Size: Ø100mm (±0.5mm tolerance)
- Stroke: 100mm (Adjustable range: 25-100mm)
- Operating Pressure: 0.05~0.9 MPa
- Cushioning: Adjustable elastic cushion (both ends)
- Piston Speed: 50~800 mm/s (lubricated condition)
- Ambient Temperature: -10℃ to 70℃
- Material: Aluminum alloy barrel, CR/NBR seals
- Port Size: Rc1/4 (G1/4 optional)
- Mounting: SB type - front flange with tapped holes
- Rod Rotation: Prevented (integrated anti-rotation design)
- Weight: 3.8kg (excluding accessories)
- Dimensions: 215mm(L) × 112mm(W) × 112mm(H)
- ISO Standard: Compliant with ISO 6432 (VDMA 24562)
Ultra-compact profile cylinder (only 20% taller than bore diameter) with dual-side stroke adjustment via hex wrench. Features chrome-plated piston rod (HRC 45-50 hardness) and integrated magnet for position sensing. Optional auto switch brackets available for SM/SMF series sensors. Requires ISO VG32 hydraulic oil mist lubrication (not pre-lubricated).
- High-density mounting in semiconductor wafer handlers
- Precision clamping in CNC tool changing systems
- Vertical lifting in automated pharmacy dispensers
- Sheet metal positioning in laser cutting machines
- Mold core pulling in compact injection molding
Installation Tip:
For vertical mounting, install lock nuts at both stroke ends. Use 12.9 grade M6x20 mounting screws
(torque 12.7±1.5Nm). Avoid side load exceeding 50N during alignment.
| Property | Property Value |
|---|---|
| sku | ACQJ100X100-40SB |
| Adjustable Stroke | <40mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 100mm |
