Airtac ACQJ80-100 Adjustable Compact Cylinder ACQJ100X100-50B
2. C-shaped retaining ring secures cylinder body with front/rear covers; Integrated riveted piston-rod structure ensures compactness and reliability;
3. Cylinder bore features precision honing for enhanced wear resistance and long service life;
4. Extended guide length on front cover delivers superior guiding performance;
5. Space-saving compact design optimizes installation in confined areas;
6. Perimeter sensor grooves enable hassle-free proximity sensor mounting;
7. Multiple standardized mounting accessories available for flexible configurations;
Category: Slim Cylinder | Brand: AIRTAC | Series: ACQJ80~100
AirTAC ACQJ100X100-50B Adjustable Thin Cylinder Specifications
- Model Range: ACQJ80~100 series
- Specific Model: ACQJ100X100-50B
- Bore Size: 100mm
- Stroke: 100mm (±0.5mm adjustment range)
- Operating Pressure: 0.05~0.8 MPa
- Temperature Range: -20℃ to 80℃
- Cushion Type: Adjustable pneumatic cushion (front/rear)
- Mounting Style: B-type foot mounting (ISO 15552 compatible)
- Port Size: M5x0.8 (G1/8 optional)
- Piston Material: Hard-anodized aluminum alloy
- Rod Material: Stainless steel (SUS304)
- Seal Material: NBR + Polyurethane (high wear resistance)
- Repeat Positioning Accuracy: ±0.1mm
- Max Speed: 500mm/s (with cushion)
- Weight: 2.8kg (without accessories)
- Dimensions:
- Extended Length: 243mm
- Retracted Length: 143mm
- Body Width: 105mm
- Height (with rod): 126mm
- Mounting Hole Spacing: 90mm x 25mm
Ultra-flat cylinder (only 43mm height without rod) with 360° adjustable cushion mechanism for precise end-position damping control. Features anti-rotation guide grooves and corrosion-resistant coating. Optional magnetic version (add "-M" suffix) for position sensing. Requires filtered air (5-50μm) with ISO VG32 lubricant recommended.
- High-density packaging machinery tooling
- Semiconductor wafer handling robots
- Automotive welding fixture positioning
- LCD panel pressurization systems
- Pharmaceutical blister packaging
Installation tip:
Maintain 0.5-1mm clearance between rod end and load during alignment.
For vertical mounting, use counterbalance valves (sold separately).
Lubricate rod weekly in high-cycle applications (>500k cycles/year).
| Property | Property Value |
|---|---|
| sku | ACQJ100X100-50B |
| Adjustable Stroke | <50mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | 100mm |
