Airtac ACQJ80-100 Adjustable Compact Cylinder ACQJ100X100-50S
2. C-shaped retaining ring secures cylinder body with front/rear covers; Integrated riveted piston-rod structure ensures compactness and reliability;
3. Cylinder bore features precision honing for enhanced wear resistance and long service life;
4. Extended guide length on front cover delivers superior guiding performance;
5. Space-saving compact design optimizes installation in confined areas;
6. Perimeter sensor grooves enable hassle-free proximity sensor mounting;
7. Multiple standardized mounting accessories available for flexible configurations;
Category: Slim Cylinder | Brand: AIRTAC | Series: ACQJ80~100
AirTAC ACQJ100X100-50S Adjustable Compact Cylinder Specifications
- Series: ACQJ80~100 (Thin Type)
- Model: ACQJ100X100-50S
- Bore size: Ø100mm
- Stroke: 100mm (adjustable)
- Operating pressure: 0.05~0.9 MPa
- Ambient temperature: -20℃~80℃
- Cushioning: Adjustable pneumatic cushion
- Port size: PT1/2 (G1/2 optional)
- Piston material: Aluminum alloy with hard anodization
- Rod material: Stainless steel SUS304
- Seal type: NBR + Polyurethane composite seals
- Mounting type: Standard ISO/VDMA front flange (50S code)
- Weight: 3.8kg ±2%
- Dimensions:
- Total length (extended): 242mm
- Body width: 128mm
- Height with mounting: 112mm
- Stroke tolerance: ±1.5mm
- Rod thread: M20×1.5
- Protection class: IP65 (standard), IP67 (optional)
- Magnetic switch compatibility: D-A93 series (slot mounting)
Ultra-flat cylinder (25% slimmer than standard models) with stroke adjustment mechanism and dual-side position sensors slots. Features wear-resistant rod coating and low-friction seals for high-frequency operation (up to 5 cycles/sec). Includes shock-absorbing end caps with 30% improved cushioning efficiency compared to previous generations.
- Press machine ejection systems
- Semiconductor wafer handling robots
- Automotive welding fixture clamping
- Food packaging vertical lift mechanisms
- Pharmaceutical blister press machines
Installation guidelines:
Max lateral load 150N. Requires 0.5mm minimum alignment tolerance.
Lubricate with ISO VG32 hydraulic oil if operating below 0.3MPa.
For vertical mounting, use rod-down orientation only.
- Theoretical thrust @0.6MPa: 4,710N (push), 4,250N (pull)
- Max piston speed: 800mm/s
- Service life: 5,000km (25℃, clean air)
| Property | Property Value |
|---|---|
| sku | ACQJ100X100-50S |
| Adjustable Stroke | <50mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 100mm |
