Airtac ACQJ80-100 Adjustable Compact Cylinder ACQJ100X100-50SB
2. C-shaped retaining ring secures cylinder body with front/rear covers; Integrated riveted piston-rod structure ensures compactness and reliability;
3. Cylinder bore features precision honing for enhanced wear resistance and long service life;
4. Extended guide length on front cover delivers superior guiding performance;
5. Space-saving compact design optimizes installation in confined areas;
6. Perimeter sensor grooves enable hassle-free proximity sensor mounting;
7. Multiple standardized mounting accessories available for flexible configurations;
Category: Slim Cylinder | Brand: AIRTAC | Series: ACQJ80~100
AirTAC ACQJ80~100 Series Adjustable Compact Cylinder ACQJ100X100-50SB Specifications
- Model: ACQJ100X100-50SB
- Series: ACQJ80~100 adjustable stroke compact cylinder
- Bore size: 100mm
- Stroke: 100mm (adjustable)
- Mounting type: Basic type with axial mounting holes
- Operating pressure: 0.05~0.9 MPa
- Cushion type: Rubber buffer + adjustable stroke mechanism
- Adjustable stroke range: 0~50% of full stroke (0~50mm for this model)
- Port size: M5x0.8 (G1/8 optional)
- Piston rod thread: M16x1.5
- Seal material: NBR (Nitrile Butadiene Rubber)
- Temperature range: -20℃ to 80℃
- Protection rating: IP54 (standard)
- Weight: 2.8kg ±5%
- Dimensions:
- Length (retracted): 175mm
- Width (body): 96mm
- Height (including rod): 145mm
- Mounting hole spacing: 80mm (longitudinal) × 60mm (transverse)
Ultra-slim profile cylinder (25% thinner than standard models) with stroke adjustment locknut for precise position control. Features double-acting operation with chromium-plated piston rod for corrosion resistance. The integrated shock absorber minimizes end-impact noise, making it ideal for clean environments.
- Precision clamping fixtures in CNC machining centers
- Material handling robots in electronics assembly lines
- Position adjustment mechanisms for solar panel production
- Packaging machine stopper controls
- Medical device actuation systems
Installation note:
When adjusting stroke length, loosen locknut with 17mm wrench before rotating adjustment screw.
Lubricate with ISO VG32 hydraulic oil (1-2 drops monthly). Avoid side-load forces exceeding 30N.
| Property | Property Value |
|---|---|
| sku | ACQJ100X100-50SB |
| Adjustable Stroke | <50mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 100mm |
