Airtac ACQJ80-100 Adjustable Compact Cylinder ACQJ100X100-75SB
2. C-shaped retaining ring secures cylinder body with front/rear covers; Integrated riveted piston-rod structure ensures compactness and reliability;
3. Cylinder bore features precision honing for enhanced wear resistance and long service life;
4. Extended guide length on front cover delivers superior guiding performance;
5. Space-saving compact design optimizes installation in confined areas;
6. Perimeter sensor grooves enable hassle-free proximity sensor mounting;
7. Multiple standardized mounting accessories available for flexible configurations;
Category: Slim Cylinder | Brand: AIRTAC | Series: ACQJ80~100
AirTAC ACQJ100X100-75SB Adjustable Compact Cylinder Specifications
- Series: ACQJ80~100 (Standard Thin Type)
- Full model: ACQJ100X100-75SB
- Bore size: 100mm
- Stroke: 100mm (adjustable)
- Adjustment range: ±2.5mm (total 5mm stroke adjustment)
- Operating pressure: 0.05-1.0 MPa
- Cushion type: Fixed rubber bumper + external stopper
- Port size: M5x0.8 (G1/8 equivalent)
- Mounting type: Basic foot mounting (ISO 15552 standard)
- Piston material: High-strength aluminum alloy (hard anodized)
- Rod material: Chrome-plated steel (Cr-Mo alloy)
- Seal type: NBR + Special wear-resistant ring
- Temperature range: -20℃ to 80℃
- Weight: 2.8kg (without accessories)
- Dimensions:
- Length: 215mm (min) / 315mm (max extended)
- Width: 100mm (cylinder body)
- Height: 114mm (including mounting foot)
- Protection rating: IP54 (standard seals)
- Lubrication: Pre-lubricated (maintenance-free for 2000km)
Ultra-slim profile cylinder featuring patented position-lock mechanism for precise stroke adjustment (±2.5mm). The double-acting design incorporates an anti-rotation guide rod and magnetic piston for sensor compatibility. Optimized for high-cycle applications with 0.5 million cycle durability under rated pressure.
- Semiconductor wafer handling robots
- PCB press-fit mechanisms
- Automated packaging line grippers
- Medical device assembly stations
- Automotive welding fixture positioning
Installation note:
Requires minimum 0.5mm alignment tolerance during mounting. For vertical installations,
use auxiliary rod support brackets (sold separately). Adjust stopper screws in 0.1mm increments
using hex key ATK-ACQJ-ADJ (included).
| Property | Property Value |
|---|---|
| sku | ACQJ100X100-75SB |
| Adjustable Stroke | 75mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 100mm |
