Airtac ACQJ80-100 Adjustable Compact Cylinder ACQJ100X125-100
2. C-shaped retaining ring secures cylinder body with front/rear covers; Integrated riveted piston-rod structure ensures compactness and reliability;
3. Cylinder bore features precision honing for enhanced wear resistance and long service life;
4. Extended guide length on front cover delivers superior guiding performance;
5. Space-saving compact design optimizes installation in confined areas;
6. Perimeter sensor grooves enable hassle-free proximity sensor mounting;
7. Multiple standardized mounting accessories available for flexible configurations;
Category: Slim Cylinder | Brand: AIRTAC | Series: ACQJ80~100
AirTAC ACQJ100X125-100 Adjustable Slim Cylinder Specifications
- Series: ACQJ80~100 (Compact Adjustable Type)
- Bore size: 100mm
- Stroke: 125mm (Adjustable range: ±5mm)
- Operating pressure: 0.05~1.0 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Rubber + Air cushion (adjustable)
- Port size: Rc1/4 (G1/4 optional)
- Mounting type: Basic (MF1) with axial accessory ports
- Piston material: High-strength aluminum alloy (surface hard anodized)
- Rod material: Chrome-plated steel (Cr-Mo alloy)
- Seal type: NBR + Special polyurethane hybrid seals
- Repeat positioning accuracy: ±0.5mm
- Weight: 3.8kg (excluding accessories)
- Dimensions:
- Length: 258mm (full extension)
- Width: 118mm (including mounting brackets)
- Height: 112mm (cylinder body diameter)
Ultra-flat cylinder (height/width ratio 0.95:1) with external stroke adjustment mechanism, featuring dual anti-rotation guide rods for precise linear motion. The T-slot design allows direct sensor mounting and supports 360° accessory port rotation. Includes wear-compensation seals for maintenance-free operation up to 5,000km travel life.
- High-speed press brake tooling adjustment systems
- Automated warehouse vertical lift positioning
- Semiconductor wafer handling robots
- Plastic injection molding ejector mechanisms
- Automotive welding fixture clamping
Installation tip:
Use locknuts on both ends when mounting in vertical orientation.
For stroke adjustment, loosen the 4mm hex screw and rotate the end cap (max 3 full turns).
Lubricate guide rods monthly with ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | ACQJ100X125-100 |
| Adjustable Stroke | 100mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | 125mm |
