Airtac ACQJ80-100 Adjustable Compact Cylinder ACQJ100X125-100S
$252.40
Regular price
$259.90
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ACQJ100X125-100S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
ACQJ80~100 Adjustable Slim Cylinder
1. Compliant with JIS industrial standards;
2. C-shaped retaining ring secures cylinder body with front/rear covers; Integrated riveted piston-rod structure ensures compactness and reliability;
3. Cylinder bore features precision honing for enhanced wear resistance and long service life;
4. Extended guide length on front cover delivers superior guiding performance;
5. Space-saving compact design optimizes installation in confined areas;
6. Perimeter sensor grooves enable hassle-free proximity sensor mounting;
7. Multiple standardized mounting accessories available for flexible configurations;
Category: Slim Cylinder | Brand: AIRTAC | Series: ACQJ80~100
Installation tip:
For vertical mounting, use locking nuts on both ends of piston rod threads.
Maintain 0.5mm alignment tolerance during bracket installation. Lubricate rod
with ISO VG32 hydraulic oil if used in high-cycle applications (>500k cycles/year).
2. C-shaped retaining ring secures cylinder body with front/rear covers; Integrated riveted piston-rod structure ensures compactness and reliability;
3. Cylinder bore features precision honing for enhanced wear resistance and long service life;
4. Extended guide length on front cover delivers superior guiding performance;
5. Space-saving compact design optimizes installation in confined areas;
6. Perimeter sensor grooves enable hassle-free proximity sensor mounting;
7. Multiple standardized mounting accessories available for flexible configurations;
Category: Slim Cylinder | Brand: AIRTAC | Series: ACQJ80~100
AirTAC ACQJ100X125-100S Adjustable Compact Cylinder Specifications
- Series: ACQJ80~100 Thin-Type Series
- Model Code: ACQJ100X125-100S
- Bore Size: 100mm
- Stroke: 125mm (±0.5mm tolerance)
- Operating Pressure: 0.05~1.0 MPa
- Piston Speed: 50~800 mm/s (optimal range)
- Cushioning: Adjustable pneumatic cushion (0-100% stroke adjustable)
- Port Size: M5x0.8 (G1/8 optional)
- Mounting Type: Basic foot mounting (ISO 15552 standard)
- Rod Thread: M16x1.5 (external)
- Material: Barrel - Aluminum alloy hard anodized, Piston Rod - SUS304 stainless steel
- Seal Material: NBR (Nitrile) with wear-resistant ring
- Temperature Range: -20℃ to 80℃ (dry air required below 0℃)
- Weight: 2.45kg ±3% (without accessories)
- Dimensions: 178mm(L) × 100mm(W) × 112mm(H) (minimum retracted length)
- Lubrication: Pre-lubricated (Oil-free operation possible with filtered air)
- Protection Class: IP65 (standard wiper design)
Ultra-flat cylinder with 23% reduced installation height compared to standard models, featuring dual-position adjustable cushion control via rotary screws. The through-rod design allows external stroke adjustment and position detection. Special wear-resistant guide rings ensure smooth operation under side load conditions.
Typical Applications:
- High-density modular automation systems
- PCB handling robots requiring precise stroke control
- Vertical lifting mechanisms in packaging machinery
- Plastic injection molding ejector systems
- Automated warehouse stacker positioners
Installation tip:
For vertical mounting, use locking nuts on both ends of piston rod threads.
Maintain 0.5mm alignment tolerance during bracket installation. Lubricate rod
with ISO VG32 hydraulic oil if used in high-cycle applications (>500k cycles/year).
| Property | Property Value |
|---|---|
| sku | ACQJ100X125-100S |
| Adjustable Stroke | 100mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 125mm |
