Airtac ACQJ80-100 Adjustable Compact Cylinder ACQJ100X125-100SB
$252.40
Regular price
$259.90
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ACQJ100X125-100SB
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
ACQJ80~100 Adjustable Slim Cylinder
1. Compliant with JIS industrial standards;
2. C-shaped retaining ring secures cylinder body with front/rear covers; Integrated riveted piston-rod structure ensures compactness and reliability;
3. Cylinder bore features precision honing for enhanced wear resistance and long service life;
4. Extended guide length on front cover delivers superior guiding performance;
5. Space-saving compact design optimizes installation in confined areas;
6. Perimeter sensor grooves enable hassle-free proximity sensor mounting;
7. Multiple standardized mounting accessories available for flexible configurations;
Category: Slim Cylinder | Brand: AIRTAC | Series: ACQJ80~100
Installation tip:
When mounting in vertical orientation, install adjustable stroke screw downward.
Allow minimum 3mm thermal expansion gap between cylinders in multi-unit arrays.
Use copper-based grease for lateral load applications.
2. C-shaped retaining ring secures cylinder body with front/rear covers; Integrated riveted piston-rod structure ensures compactness and reliability;
3. Cylinder bore features precision honing for enhanced wear resistance and long service life;
4. Extended guide length on front cover delivers superior guiding performance;
5. Space-saving compact design optimizes installation in confined areas;
6. Perimeter sensor grooves enable hassle-free proximity sensor mounting;
7. Multiple standardized mounting accessories available for flexible configurations;
Category: Slim Cylinder | Brand: AIRTAC | Series: ACQJ80~100
AirTAC ACQJ100X125-100SB Adjustable Compact Cylinder Specifications
- Series: ACQJ80~100 (Thin-line adjustable cylinder series)
- Model: ACQJ100X125-100SB
- Bore size: Ø100mm ±0.1mm
- Stroke: 125mm (adjustable ±2mm)
- Operating pressure: 0.1~0.9 MPa
- Cushion type: Adjustable pneumatic cushion
- Action type: Double-acting
- Mounting style: Standard flange mounting (MF12)
- Port size: PT1/2 (G1/2 optional)
- Temperature range: -20℃ to 80℃
- Material: Aluminum alloy barrel, CR12MoV piston rod
- Seal material: NBR with wear-resistant ring
- Weight: 5.8kg ±3%
- Dimensions (L×W×H): 300mm × 150mm × 120mm (including accessories)
- Rod thread: M20×1.5 external thread
- Max theoretical force: 706N @0.6MPa (extend), 642N @0.6MPa (retract)
- Max speed: 500mm/s
- Lubrication: Pre-lubricated (DIN standard VDL oil)
Ultra-slim profile cylinder (23% thinner than standard models) with precision stroke adjustment mechanism. Features anodized corrosion-resistant surface and integrated cushion valve for smooth end-of-stroke deceleration. The SB suffix indicates special brass bushing reinforcement for lateral load applications.
Typical Applications:
- High-density automation workstations
- Plastic injection molding ejectors
- CNC machine tool clamping systems
- Automotive welding fixture positioning
- Food packaging press mechanisms
Installation tip:
When mounting in vertical orientation, install adjustable stroke screw downward.
Allow minimum 3mm thermal expansion gap between cylinders in multi-unit arrays.
Use copper-based grease for lateral load applications.
Stroke Adjustment:
Rotate hex socket (5mm key) clockwise to decrease stroke (max 2mm reduction per full rotation).
Lock adjustment with M5 set screw after calibration. Requires 0.3Nm torque for fine-tuning.
| Property | Property Value |
|---|---|
| sku | ACQJ100X125-100SB |
| Adjustable Stroke | 100mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 125mm |
