Airtac ACQJ80-100 Adjustable Compact Cylinder ACQJ100X125-10B
2. C-shaped retaining ring secures cylinder body with front/rear covers; Integrated riveted piston-rod structure ensures compactness and reliability;
3. Cylinder bore features precision honing for enhanced wear resistance and long service life;
4. Extended guide length on front cover delivers superior guiding performance;
5. Space-saving compact design optimizes installation in confined areas;
6. Perimeter sensor grooves enable hassle-free proximity sensor mounting;
7. Multiple standardized mounting accessories available for flexible configurations;
Category: Slim Cylinder | Brand: AIRTAC | Series: ACQJ80~100
AirTAC ACQJ Series Adjustable Compact Cylinder - ACQJ100X125-10B Details
- Model: ACQJ100X125-10B
- Series: ACQJ80~100 adjustable thin-type
- Bore size: Ø100 mm
- Stroke: 125 mm (adjustable)
- Cylinder type: Double-acting
- Mounting style: Basic type (MF1) with axial mounting holes
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -20℃ to 80℃
- Cushion type: Fixed buffer + adjustable stroke mechanism
- Seal material: NBR (nitrile rubber) standard
- Port size: G3/8 (ISO standard)
- Piston rod thread: M20×1.5
- Adjustable stroke range: 0–125 mm (mechanical stopper)
- Repeat positioning accuracy: ±0.5 mm
- Max. piston speed: 500 mm/s
- Weight: 2.5 kg ±3%
- Dimensions (L×W×H): 225×100×100 mm (full extension)
- Body material: Aluminum alloy (anodized surface)
- Rod material: Chrome-plated steel
Ultra-slim profile cylinder (30% thinner than standard models) with integrated stroke adjustment mechanism. Features precision-ground rod and wear-resistant guides for smooth linear motion. Includes auto-lubrication design with maintenance-free operation for 3,000 km travel distance. Compatible with magnetic sensors (sensor groove pre-machined).
- Space-constrained automation lines (electronics assembly)
- Precision press-fit operations in automotive manufacturing
- Variable height positioning in packaging machinery
- Clamping fixtures for CNC machining centers
- Medical device actuation systems
Installation notes:
Maintain parallel alignment during mounting. Use locknuts (not included) on adjustable stoppers.
Lubricate rod weekly in high-cycle applications (>500 cycles/min). Avoid side loads exceeding 50N.
| Property | Property Value |
|---|---|
| sku | ACQJ100X125-10B |
| Adjustable Stroke | <10mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | 125mm |
