Airtac ACQJ80-100 Adjustable Compact Cylinder ACQJ100X125-10S
2. C-shaped retaining ring secures cylinder body with front/rear covers; Integrated riveted piston-rod structure ensures compactness and reliability;
3. Cylinder bore features precision honing for enhanced wear resistance and long service life;
4. Extended guide length on front cover delivers superior guiding performance;
5. Space-saving compact design optimizes installation in confined areas;
6. Perimeter sensor grooves enable hassle-free proximity sensor mounting;
7. Multiple standardized mounting accessories available for flexible configurations;
Category: Slim Cylinder | Brand: AIRTAC | Series: ACQJ80~100
AirTAC ACQJ80~100 Adjustable Compact Cylinder ACQJ100X125-10S Specifications
- Series: ACQJ (Thin-type Adjustable Cushion)
- Bore size: 100mm
- Stroke: 125mm
- Mounting type: Basic (MF1) with fixed mounting holes
- Cushion type: Adjustable buffer (10S code)
- Operating pressure: 0.1–0.9 MPa
- Temperature range: -20℃ to 80℃
- Port size: G3/8 (standard) with M12x1.25 thread adapter
- Piston rod thread: M20x1.5
- Material:
- Cylinder tube: Aluminum alloy (hard anodized)
- Piston rod: Chrome-plated carbon steel
- Seals: NBR (nitrile rubber)
- Weight: 5.8kg ±2% (without accessories)
- Dimensions:
- Total length: 273mm (at full extension)
- Body width: 120mm (mounting surface)
- Height: 100mm (including cushion screws)
- Mounting hole spacing: 80mm x 80mm (MF1 pattern)
Ultra-flat cylinder (only 42mm height without rod) with dual adjustable pneumatic cushions, designed for space-constrained applications requiring precise end-position damping control. Features wear-resistant rod guide bushings and IP65 protection rating. Optional magnetic piston version (add "-M" suffix) for position sensing.
- High-speed pick-and-place systems in electronics assembly
- Clamping fixtures for CNC machine tooling
- Cartesian robot Z-axis actuation
- Semiconductor wafer handling equipment
- Automotive door panel pressing mechanisms
Installation tip:
When using in vertical orientation, install a lubricator in the air line and
perform stroke adjustment with 0.3-0.5 MPa pressure. Cushion needle valves
require 1/8~1/4 turn adjustment from full closed position.
| Property | Property Value |
|---|---|
| sku | ACQJ100X125-10S |
| Adjustable Stroke | <10mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 125mm |
