Airtac ACQJ80-100 Adjustable Compact Cylinder ACQJ100X125-10SB
2. C-shaped retaining ring secures cylinder body with front/rear covers; Integrated riveted piston-rod structure ensures compactness and reliability;
3. Cylinder bore features precision honing for enhanced wear resistance and long service life;
4. Extended guide length on front cover delivers superior guiding performance;
5. Space-saving compact design optimizes installation in confined areas;
6. Perimeter sensor grooves enable hassle-free proximity sensor mounting;
7. Multiple standardized mounting accessories available for flexible configurations;
Category: Slim Cylinder | Brand: AIRTAC | Series: ACQJ80~100
AirTAC ACQJ100X125-10SB Adjustable Compact Cylinder Specifications
- Series: ACQJ80~100 (Compact Adjustable Stroke)
- Model Code: ACQJ100X125-10SB
- Bore Size: 100mm
- Stroke: 125mm (adjustable)
- Mounting Type: Front Flange (MF1) with integrated mounting slots
- Operating Pressure: 0.05~0.9 MPa
- Temperature Range: -20℃ to 80℃
- Cushioning: Adjustable buffer (both ends)
- Piston Speed: 50~800 mm/s
- Port Size: G3/8 (BSPP thread)
- Rod End: M20×1.5 external thread
- Cylinder Material: Aluminum alloy barrel, chromium-plated piston rod
- Seal Material: NBR + PU combination
- Weight: 3.8kg ±2%
- Dimensions (L×W×H):
- Basic Length: 206mm (retracted)
- Full Extension: 331mm
- Body Width: 112mm
- Height with Mount: 132mm
- ISO Standard: Compliant with ISO 6432 (mounting dimensions)
Ultra-flat cylinder (28% slimmer than standard models) featuring stroke adjustment mechanism with ±3mm precision. The dual-chamber buffer system minimizes end-impact while maintaining 92% mechanical efficiency. Integrated magnet slot supports D-A93 series sensors. Optional anti-rotation rod available for special applications.
- Precision press machines (die height adjustment)
- Automated packaging line gripper positioning
- Semiconductor wafer handling systems
- Automotive welding fixture clamping
- Vertical lift mechanisms in logistics sorting
Maintenance Tip:
Lubricate through air supply (ISO VG32 recommended) every 2,000km of cumulative stroke.
Use locknut wrench SZAT-12 for stroke adjustment to prevent thread damage.
- Magnetic Switch: D-A93 (2-wire) / D-A9S (3-wire)
- Installation Torque: 0.5~0.7 N·m
- Sensor Gap: 1.5±0.5mm from cylinder surface
| Property | Property Value |
|---|---|
| sku | ACQJ100X125-10SB |
| Adjustable Stroke | <10mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 125mm |
