Airtac Adjustable Compact Cylinder ACQJ50~63 ACQJ50X100-50
1. Complies with JIS standards;
2. C-shaped retaining ring secures cylinder body to front/rear covers, with riveted piston-rod connection for compact and reliable construction;
3. Precision-honed inner bore ensures superior wear resistance and long-term durability;
4. Extended front cover guide length enhances directional stability;
5. Space-saving profile minimizes installation footprint;
6. Perimeter sensor slots enable effortless sensor integration;
7. Multiple mounting accessory configurations available.
Category: Compact Cylinder | Brand: AIRTAC | Series: ACQJ50~63
AirTAC ACQJ50~63 Adjustable Compact Cylinder ACQJ50X100-50 Specifications
- Model: ACQJ50X100-50
- Series: ACQJ (50-63mm bore size range)
- Bore diameter: 50mm
- Stroke: 100mm (±0.5mm tolerance)
- Operating pressure: 0.1-0.9 MPa
- Cushion type: Adjustable pneumatic cushion (dual-side)
- Action type: Double acting
- Mounting style: Basic type (no built-in mount)
- Port size: M5x0.8 (standard) / NPT1/8 optional
- Piston rod thread: M10x1.25
- Tube material: Anodized aluminum alloy
- Seal material: NBR (nitrile rubber)
- Operating temperature: -20℃ to 80℃
- Weight: 1.2kg (excluding accessories)
- Dimensions:
- Length: 182mm (full extension)
- Width: 63mm (max cylinder width)
- Height: 50mm (body height)
- ISO standard: 6432 compliant
- Lubrication: Pre-lubricated (non-re-lube design)
Ultra-slim profile cylinder (50% thinner than standard models) with precision-adjustable cushions for controlled deceleration. Features wear-resistant chromium-plated piston rod and corrosion-resistant body treatment. The modular design allows easy integration with ISO 6432-compatible accessories. Optimal for medium-duty pushing/pulling applications requiring space optimization.
- PCB handling robots in electronics manufacturing
- Clamping mechanisms in CNC tool changers
- Conveyor gate actuators in packaging lines
- Medical device positioning systems
- Automated test equipment sample handlers
Installation tip:
Use locknuts (not included) on both ends for axial load support.
Adjust cushion screws in 1/4 turns while testing at operational speed.
Maintain 0.3-0.6 MPa pressure during adjustment for optimal damping.
| Property | Property Value |
|---|---|
| sku | ACQJ50X100-50 |
| Adjustable Stroke | <50mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
