Airtac Adjustable Compact Cylinder ACQJ50~63 ACQJ50X100-50SB
1. Complies with JIS standards;
2. C-shaped retaining ring secures cylinder body to front/rear covers, with riveted piston-rod connection for compact and reliable construction;
3. Precision-honed inner bore ensures superior wear resistance and long-term durability;
4. Extended front cover guide length enhances directional stability;
5. Space-saving profile minimizes installation footprint;
6. Perimeter sensor slots enable effortless sensor integration;
7. Multiple mounting accessory configurations available.
Category: Compact Cylinder | Brand: AIRTAC | Series: ACQJ50~63
AirTAC ACQJ50X100-50SB Adjustable Compact Cylinder Specifications
- Series: ACQJ50~63 (ISO 6432 compliant)
- Bore size: 50mm (standard series includes 50/63mm variants)
- Stroke: 100mm (adjustable with ±0.5mm positioning accuracy)
- Working pressure: 0.05-1.0 MPa (optimal at 0.7 MPa)
- Cushion type: Adjustable pneumatic cushion (dual-side)
- Mounting style: Basic type (MF1) with front threaded mounting
- Port size: M5x0.8 (standard) / NPT1/8 optional
- Operating temperature: -20℃ to +80℃ (with dry air)
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Stainless steel (SUS304)
- Seals: NBR rubber (oil-resistant)
- Weight: 2.8kg (with rod end accessories)
- Dimensions: 178mm(L) × 50mm(W) × 50mm(H) (retracted length)
- Max thrust: 1375N @0.7MPa (push/pull force)
- Speed range: 50-750mm/s (with cushion adjustment)
- Protection class: IP40 (dust protected)
Ultra-slim profile cylinder (only 50mm width) with precision stroke adjustment, featuring dual adjustable air cushions for smooth end-position damping. The chrome-plated piston rod and integrated wear ring ensure over 3,000km service life under standard conditions. Includes auto-switch mounting slots for sensor compatibility.
- High-density automation cells with space constraints
- Precision part insertion in PCB assembly lines
- Vertical lifting mechanisms in packaging machinery
- Medical device actuation requiring smooth motion
- Cleanroom-compatible automation systems
Installation tips:
Maintain 0.5mm minimum clearance between rod and guide mechanisms.
Lubricate with ISO VG32 turbine oil for high-cycle applications.
Use rod-end bearings for angular misalignment over ±2°.
| Property | Property Value |
|---|---|
| sku | ACQJ50X100-50SB |
| Adjustable Stroke | <50mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
