Airtac Adjustable Compact Cylinder ACQJ50~63 ACQJ50X100-75
1. Complies with JIS standards;
2. C-shaped retaining ring secures cylinder body to front/rear covers, with riveted piston-rod connection for compact and reliable construction;
3. Precision-honed inner bore ensures superior wear resistance and long-term durability;
4. Extended front cover guide length enhances directional stability;
5. Space-saving profile minimizes installation footprint;
6. Perimeter sensor slots enable effortless sensor integration;
7. Multiple mounting accessory configurations available.
Category: Compact Cylinder | Brand: AIRTAC | Series: ACQJ50~63
AirTAC ACQJ50~63 Adjustable Compact Cylinder ACQJ50X100-75 Specifications
- Model Series: ACQJ50~63 (50mm/63mm bore sizes)
- Specific Model: ACQJ50X100-75
- Bore Size: 50mm
- Stroke: 100mm
- Adjustment Range: 0-75mm (external screw-type stroke adjustment)
- Operating Pressure: 0.1~0.9 MPa
- Cushioning: Adjustable elastic cushion (both ends)
- Mounting Style: Fixed foot (Standard MF1) with accessory mounting options
- Port Size: M5x0.8 (G1/8 adapter optional)
- Piston Speed: 50~800 mm/s
- Ambient Temperature: -20℃ to 80℃
- Material: Aluminum alloy cylinder tube, Chrome-plated piston rod
- Seal Material: NBR (Nitrile rubber)
- Protection Class: IP65 (standard dust/water resistance)
- Weight: 1.8kg ±2% (including mounting hardware)
- Dimensions:
- Length: 176mm (minimum retracted length)
- Width: 56mm (maximum mounting base width)
- Height: 63mm (including adjustment mechanism)
Ultra-flat cylinder (18% slimmer than standard models) with external stroke adjustment mechanism, featuring dual-axis position detection slots for sensor compatibility. The chrome-plated piston rod incorporates a wear-resistant coating (WC-1 grade) for >5,000km service life. Includes anti-rotation guide design for precision linear motion.
- PCB handling robots requiring millimeter-level positioning
- Pharmaceutical blister packaging machine actuators
- Automated warehouse vertical lift positioning systems
- Semiconductor wafer cassette elevators
- 3C product assembly line clamping devices
Installation protocol:
Apply axis alignment tool (P/N: ACQJ-AL50) during mounting. Lubricate adjustment screw monthly with ISO VG32 hydraulic oil. Maximum side load: ≤15N. For vertical installations, use optional air bleeding kit (ACQJ-VK2).
| Property | Property Value |
|---|---|
| sku | ACQJ50X100-75 |
| Adjustable Stroke | 75mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
