Airtac Adjustable Compact Cylinder ACQJ50~63 ACQJ50X60-40S
1. Complies with JIS standards;
2. C-shaped retaining ring secures cylinder body to front/rear covers, with riveted piston-rod connection for compact and reliable construction;
3. Precision-honed inner bore ensures superior wear resistance and long-term durability;
4. Extended front cover guide length enhances directional stability;
5. Space-saving profile minimizes installation footprint;
6. Perimeter sensor slots enable effortless sensor integration;
7. Multiple mounting accessory configurations available.
Category: Compact Cylinder | Brand: AIRTAC | Series: ACQJ50~63
AirTAC ACQJ50~63 Adjustable Compact Cylinder ACQJ50X60-40S Specifications
- Series: ACQJ (Thin-type adjustable cylinder series)
- Full model: ACQJ50X60-40S
- Bore size: 50mm (available in 50/63mm variants)
- Stroke: 60mm (customizable from 10-300mm)
- Mounting type: Basic type (MF1)
- Adjustable cushioning: Both sides (precision stroke adjustment)
- Operating pressure: 0.1-0.9 MPa
- Temperature range: -20℃ to 80℃
- Port size: PT1/8 (G1/8 optional)
- Piston speed: 50-1000 mm/s
- Cushion length: 8mm (adjustable via screw)
- Material:
- Tube: Aluminum alloy (hard anodized)
- Piston rod: SUS304 stainless steel
- Seals: NBR + PU combination
- Weight: 1.2kg ±5%
- Dimensions:
- Total length: 140mm (at mid-stroke)
- Width: 80mm (mounting base surface)
- Height: 80mm (including cushion screws)
- Protection class: IP54 (standard)/IP67 (optional)
Ultra-slim profile cylinder (40% thinner than standard models) with precision stroke adjustment capability. Features dual anti-rotation guide rods and magnetic piston for position sensing compatibility. The T-slot mounting surface allows direct installation of accessories. Special buffer design reduces end-impact noise to <75dB.
- PCB handling robots in electronics manufacturing
- Precision clamping devices for CNC tool changers
- Medical device assembly lines
- High-speed sorting mechanisms (up to 3 cycles/sec)
- Cleanroom automation systems
Installation guidelines:
Use M5x0.8 mounting screws with 12N·m torque limit. Maintain 0.5mm minimum clearance between magnetic switch and cylinder body. Lubricate with ISO VG32 turbine oil if operating below -10℃.
| Property | Property Value |
|---|---|
| sku | ACQJ50X60-40S |
| Adjustable Stroke | <40mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 60mm |
