Airtac AirTAC 2KW Fluid Control Valve 2KW03006BI
1. Direct-acting normally open 2/2-way solenoid valve with rapid response and high sensitivity;
2. Wide pressure range compatibility: Available in Ultra-high Pressure (X), High Pressure (H), Standard, and Large Flow (L) configurations;
3. Versatile pilot-operated normally open 2/2-way solenoid valve featuring fast switching and high flow capacity;
4. Compact structure with space-saving design, lightweight construction, and tool-free maintenance;
5. Brass valve body with Class B thermal-rated coil. Standard FKM (Fluoroelastomer) seals ensure compatibility with multiple media. Custom seal materials available through technical consultation;
6. IP65-rated coil protection, available in direct lead-wire or DIN connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KW
AirTAC 2KW03006BI Fluid Control Valve Specifications
- Model: 2KW03006BI
- Type: 3-position, 5-way closed center (double solenoid)
- Port size: G1/8 (ISO228-1 standard)
- Operating pressure: 0.2–1.0 MPa (29–145 psi)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Max flow rate: 750 L/min (ANR)
- Response time: ≤15ms (at 0.5MPa)
- Seal material: Fluorocarbon rubber (FKM) for high temp resistance
- Temperature range: -10℃ to 80℃ (14°F to 176°F)
- Weight: 0.82 kg (1.81 lbs)
- Dimensions: 80mm(L) × 50mm(W) × 65mm(H)
- Port thread depth: 12mm (minimum engagement)
- Coil insulation class: Class F (155℃)
- Protection rating: IP67 (dust/water resistant)
- Hysteresis: ≤0.02 MPa
- Manual override: Built-in push-button (both solenoids)
High-performance proportional control valve with position feedback capability, featuring dual redundant seals and anti-vibration design. The aluminum alloy body with hard anodized surface treatment ensures durability in harsh environments. Requires 5μm filtration (40μm for non-critical applications) and lubricated air (ISO VG32 equivalent).
- Precision pressure regulation in semiconductor manufacturing
- Automated assembly line clamping systems
- Hydraulic pilot control in injection molding machines
- Robotic end-effector force control
- Cleanroom-compatible pneumatic circuits
Installation note:
Mount with vibration-damping gaskets when used in mobile equipment.
Maintain 0.3-0.5MPa pilot pressure for optimal spool response.
Allow 20mm clearance above valve for heat dissipation.
| Property | Property Value |
|---|---|
| sku | 2KW03006BI |
| Port Size | PT1/8 |
| Flow Aperture | <3mm> |
| Coil Voltage | DC24V |
